Home >  Biscuit machine >  PLC control 14 heads biscuit weighing machine
PLC control 14 heads biscuit weighing machine PLC control 14 heads biscuit weighing machine

PLC control 14 heads biscuit weighing machine

Application: It is suitable for weighing of granule, slice shape such as cereal, pasta, candy, seed, chips, coffee bean, nut, puffy food, biscuit, chocolate, pet food,...
  • INFO@LDFOODMACHINE.COM | Get Latest Price
  • 1100(L)*1100(W)*1780(H) mm
  • Within 5 working days
  • paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
  • Contact with us
  • China
  • Biscuit machine
  • CE
  • Biscuit machine

Product Description

Application:

It is suitable for weighing of granule, slice shape such as cereal, pasta, candy, seed, chips, coffee bean, nut, puffy food, biscuit, chocolate, pet food, frozen foods, etc. It is also suitable for non-food industry such as screws, bolts and plastic components.

Main Features:

1,Original program can be restored.

2,Easy cleaning and maintenance with clean function, all hoppers can stay open.

3,Piece counting function.

4,IP65 certificate.

5,Unqualified weight reject.

6,Step motor angle can be set according to different product.

7,99 program can be preset.

8,Stagger dump prevents products blockage.

Special Features:

1,Modular electronic system makes function expanding and maintenance easier and at lowest cost.

2,Professional A/D card with high accuracy and stability. Interchange is available.

3,HMI program with different authority management more user-friendly.

4,HMI program can be upgraded by U-disk.

5,PLC control system applied in the weigher and it makes machine more stable and low fault rate. Makes machine more stable and low fault rate.Funtions expanding more easier.

6,Application software can be upgraded by memory card.

7,Remote control is available

Technical Parameters:

Model

TY-P14L1.6

TY-P14L2.5

Weighing Range

10~1500g

10~3000g

Weighing Accuracy

±0.1~1.5g

±0.1~2g

Max.Weighing Speed

120WPM

120WPM

Hopper Capacity

1.6L

2.5L

Operation Panel

7 Inch touch screen

Control system

PLC

Power Supply

AC220V±10% 50HZ/60HZ 2KW

Packing Dimension

1100(L)*1100(W)*1780(H) mm

Net Weight

366KGS

Packing Weight

495KGS

width: 760px; display: inline; height: 538px;

width: 760px; display: inline; height: 746px;

width: 640px; display: inline; height: 800px;

width: 760px; display: inline; height: 497px;

width: 760px; display: inline; height: 497px;

width: 760px; display: inline; height: 380px;

width: 760px; display: inline; height: 760px;

width: 760px; display: inline; height: 617px;

width: 760px; display: inline; height: 380px;

width: 760px; display: inline; height: 657px;

PLC control 14 heads biscuit weighing machine is suitable for foods such as casual products, soy products, meat, and aquatic products. is widely used in large, medium and small-sized fried food manufacturers, school canteens, and large-scale restaurants.
Jinan Joysun Machinery Co., Ltd. is a modern food machinery and equipment manufacturing enterprise integrating R&D, manufacturing, sales, and after-sales services.
The main production of food frying equipment, cleaning equipment, blanching cooking equipment, pasteurization line, drying machine, vacuum packaging machines and other food processing equipment.
PLC control 14 heads biscuit weighing machine is the essence of absorbing the same kind of equipment, retaining the advantages of large-scale equipment for enrichment, and referencing the user's feedback information throughout the country for design and development.
has the characteristics of low one-time investment, low energy consumption, multiple functions, small size, high profit, convenient use and maintenance. The full set of equipment consists of peeling, slicing (strips), fluttering, dehydration, oil-water mixed frying, degreasing, seasoning, packaging and auxiliary equipment.
