Automatic Puffed Whole Grain Breakfast Cereal Food Packaging Machine

Product Description Application This fully automatic model is capable to accomplish bag making, weighing, filling, sealing, cutting, date printing, etc. It's...
  • INFO@LDFOODMACHINE.COM | Get Latest Price
  • L1570mm x W1255mm x H1600mm
  • Check with us
  • paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
  • Contact with us
  • China
  • Cereal Breakfast Food machine
  • CE, CE
  • Cereal Breakfast Food machine

Product Description

Product Description


Application


This fully automatic model is capable to accomplish bag making, weighing, filling, sealing, cutting, date printing, etc. It's suitable for a wide range of free flowing granule or bulk products that need high weighing accuracy, such as cereals, potato chips, cookies, puffed food, crispy rice, popcorn, pasta, fried snacks, frozen food, medicine, bolts, nuts, etc.


width: 750px; height: 750px; margin-left: 0px; margin-top: 0px;
Specifications
Item VFC200G VFC250G VFC300G VFC350G
Output 5-70 bmp 5-70 bmp 5-50 bmp 5-50 bmp
Fiiling Range 100ml-1200ml 100ml-3000ml 100ml-5000ml 100ml-15l
Accuracy ± 1%~2%
Bag Length 50mm-300mm 80mm-360mm 100mm-400mm 100mm-500mm
Bag Width
80mm-200mm 80mm-250mm 120mm-350mm 120mm-350mm
Bag Type Pillow Bag, Gusset Bag
Bag Material Heat Sealable PE film & Laminatd Film, such as PE/PET, VMPET, Filter paper, etc.
Film Thickness 0.05mm-0.09mm
Film Roll Inner Diameter 75mm
Film Roll Outer Diameter Max. 350mm
Max. Film Width 420mm 520mm 720mm 820mm
Gas Consumption 0.3m3/min 0.3m3/min 0.5m3/min 0.8m3/min
Air Consumption 0.65mpa 0.65mpa 0.65mpa 0.65mpa
Power 380V, 2.2kW 380V, 4kW 380V, 5kW 380V, 5kW
Machine Dimension L x W x H (mm) 1470x1160x1450 1570x1255x1600 1745x1362x1700 1600x1530x2110
Note: Techanical data are subject to change.


Main Features


1. Color touch screen with industrial PC, all machine parameters can be adjusted through this EN/CN HMI for a very flexible and quick change over machine.


2. All main important electrical components are from reliable brands, like FRENCH SCHNEIDER, JAPANESS OMRON, which ensures Automatic Puffed Whole Grain Breakfast Cereal Food Packaging Machine lifetime.


3. Pneumatical sealing blocks, higher speed


4. Servo film-pulling for stable precise bag length


5. Capacity to program Data for 10 products.


6. Independent temperature control system, accuracy up tp ±1ºC, which makes it possible to use various packaging film.


7. Automatic stop when being opened by untrained personnel.


8. Closed estructure frame construction, made of stainless steel 304.


9. Environmental, low noise and clean working area.

Electric Componentswidth: 750px; height: 320px; margin-left: 0px; margin-top: 0px;

Electrical Cabinet

To ensure reliable performance, we choose French Schneider for important electric components.

width: 371px; height: 200px; margin-left: 0px; margin-top: 0px; width: 371px; height: 200px; margin-left: 0px; margin-top: 0px;

Circut-breaker

PLC Controller


width: 371px; height: 220px; margin-left: 0px; margin-top: 0px; width: 371px; height: 220px; margin-left: 0px; margin-top: 0px;

Servo Drive


Solid Relays


width: 371px; height: 220px; margin-left: 0px; margin-top: 0px; width: 371px; height: 200px; margin-left: 0px; margin-top: 0px;

Contactor


Intermediate Relays


width: 371px; height: 200px; margin-left: 0px; margin-top: 0px; width: 371px; height: 200px; margin-left: 0px; margin-top: 0px;

Emergency Button


Power Supply


Optionswidth: 750px; height: 400px; margin-left: 0px; margin-top: 0px;Packing & Deliverywidth: 245px; height: 234px; margin-left: 0px; margin-top: 0px; width: 245px; height: 234px; margin-left: 0px; margin-top: 0px; width: 245px; height: 234px; margin-left: 0px; margin-top: 0px;

Protective Plastic Film


Export Wooden Case


Safe Land TransportationRelated Productswidth: 371px; height: 200px; margin-left: 0px; margin-top: 0px; width: 371px; height: 200px; margin-left: 0px; margin-top: 0px;

Automatic Baby Breakfast Cereal Corn Flakes Pops Packaging Machine

Automatic Puffed Corn Rice Oats Whole Grain Cereal Packaging Machine
