Home >  Cereal Breakfast Food machine >  breakfast cereal production line food extruder snacks corn ring making machinery
breakfast cereal production line food extruder snacks corn ring making machinery breakfast cereal production line food extruder snacks corn ring making machinery breakfast cereal production line food extruder snacks corn ring making machinery

breakfast cereal production line food extruder snacks corn ring making machinery

Related products fried bugles snack machine kurkure cheetos machine 2d&3d pellet snack machine Product Description breakfast...
  • INFO@LDFOODMACHINE.COM | Get Latest Price
  • 2300*1650*2100mm
  • Check with us
  • paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
  • Contact with us
  • China
  • Cereal Breakfast Food machine
  • CE ISO9001 SGS
  • Cereal Breakfast Food machine

Product Description

Related products width: 312px; height: 234px; margin-top: 0px; margin-left: -37px;

width: 244.65px; height: 244.65px; margin-top: -11px; margin-left: 0px; width: 244.65px; height: 235.51px; margin-top: 0px; margin-left: 0px;

fried bugles snack machine

kurkure cheetos machine

2d&3d pellet snack machine

Product Description

breakfast cereal production line food extruder snacks corn ring making machinery introduction:
Corn flakes is a kind of crispy food with strong grain taste.Adopting corn flour and other grain flours as their raw materials, through mixing,extrusion, flaking, drying, high temperature baking , flavoring and cooling , the raw materials will be made into tasty corn flakes and breakfast cereals . Just by changing the dies or choosing suitable production process, different shapes breakfast cereals can be available such as ring ,ball ,flake,star,letter etc .The corn flakes production line is highly automatic and high efficiency. All the machines choose the famous band motors and best accessories for installation. What's more ,we can configure the machines as your need

Main Features of breakfast cereal production line food extruder snacks corn ring making machinery
1) Simple structure in linear type ,easy in installation and maintation.
2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.
3) High pressure double crank to control the die opening and closing.
4) Running in a high automatization and intellectualization,no pollution
5) Apply a linker to connect with the air conveyor ,which can directly inline with filling machine .

Flow chart :

Mixer — screw conveyer— Twin-screw extruder —Sifter—Air conveyer —Flaking machine —Air conveyer — Three-layer oven — Hoister — Microwave Oven —Melting sugar machine —Sprayer sugar—Hoister —Roller — Air compressor— Hoister — Five-layer oven— Cooing machine

width: 750px; height: 231px; margin-left: 0px; margin-top: 0px;

Flow chart diagram:

Our engineer could design the layout drawing according to your dimension of the factory for the fish feed machines

width: 750px; height: 302.25px; margin-top: 0px; margin-left: 0px;

Technical parameter for snacks food extruder

Model InstalledPower(KW) Power Consumption(kw) Capacity(kg/h) Dimension(m)
DSE65 processing line 74 52 100-150 17*1.2*2.2
DSE70 processing line 95 70 200-300 20*1.5*2.2
DSE85 processing line 139 102 300-500 28*3.5*4.3

Raw material:

Corn, rice, millets, wheat, oat, barley etc as ingredients. Please note that all the materials should be in powder(flour) or grits form.

width: 750px; height: 204px; margin-top: 0px; margin-left: 0px;

Sample of breakfast cereal production line food extruder snacks corn ring making machinery :

width: 750px; height: 732.955px; margin-left: 0px; margin-top: 0px;

Equipment list in the breakfast cereal production line food extruder snacks corn ring making machinery production line:

mixer→screw conveyor→twin screw extruder→air conveyor→dryer→hoister→flavoring drum and oil sprayer→cooling machine→packing machine

1)mixer of breakfast cereal production line food extruder snacks corn ring making machinery

width: 426.66px; height: 320px; margin-top: 0px; margin-left: -36.66px;
Name Mixer
Usage To mix the raw materials evenly, fast speed, no leakage.
Type including Single axle and double shaft mixer
Motor 3kw, 4kw, 7.5kw etc.
Capacity 20kg/time, 50kg/time, 100kg/time, 200kg/time, 500kg/time etc.
Material stainless steel, carbon steel

2)extruder of breakfast cereal production line food extruder snacks corn ring making machinery

width: 371px; height: 371px; margin-top: -26.66px; margin-left: 0px;
Name Twin screw extruder(wet type/dry type)
Usage To extrude the raw materials and make them to the required shape and size of the breakfast cereal production line food extruder snacks corn ring making machinery pellets by mould
model DSE65, 70, 75, 90, 95, 120, 135
Motor 22kw, 30kw, 55kw, 75kw, 90kw, 110kw etc.
Capacity 100kg/h to 10 ton/h
Material Screw materials 38CrMoAl
stainless steel, carbon steel

3)Flaking machine of breakfast cereal production line food extruder snacks corn ring making machinery

width: 371px; height: 333.9px; margin-left: 0px; margin-top: 0px;
Name Flaking machine
Usage The material are pressed into a sheet by two rotary circular rolls
Type electrical
Motor 1.1kw, 2.2kw, 5.5kw
Capacity 100kg/h to 500kg/h
Material stainless steel

4)oven of breakfast cereal production line food extruder snacks corn ring making machinery

width: 371px; height: 339.09px; margin-top: -5px; margin-left: 0px;
Name Dryer (oven)
Usage the expanded food go through the “s” passage, to be dried to increase the self life.
Type electrical, steam, gas fired, diesel fired heating type
Model KX-3-5, KX-5-5, KX-5-8, KX-5-10, KX-7-10 etc.
Capacity 100kg/h to 10 ton/h
Material stainless steel, carbon steel

5)microwava oven of breakfast cereal production line food extruder snacks corn ring making machinery

width: 461.76px; height: 320px; margin-left: -71.6667px; margin-top: 0px;
Name microwava oven
Usage two times puffed ,The internal water molecules rub each other to generate heat to expand the material
Type electrical
Model KX-3-5, KX-5-5, KX-5-8, KX-5-10, KX-7-10 etc.
Capacity 100kg/h to 10 ton/h
Material stainless steel

6)flavoring of breakfast cereal production line food extruder snacks corn ring making machinery

width: 371px; height: 371px; margin-top: 0px; margin-left: 0px;
Name Flavoring machine
Usage To mix the oil and flavors on the surface of the fish feed
Type single and double flavoring drum
Motor 0.75kw
Capacity 100kg/h to 10 ton/h
Material stainless steel

7)packaging of breakfast cereal production line food extruder snacks corn ring making machinery

width: 371px; height: 371px; margin-top: -20.83px; margin-left: 0px;
Name Packaging machine
Usage To pack the breakfast cereal production line food extruder snacks corn ring making machinery with required weight
Flowing Process Manual Bag placing→Automatic filling→Automatic weighing→ Automatic bag conveyor→Automatic bag sewing or heat sealing
Weight range 1-5kg/bag, 5-25kg/bag, 25-50kg/bag
Material stainless steel, carbon steel
Type Automatic
Production process

Bright company is in strict accordance with the industrial standards for cutting, bending, welding, strict

control of process quality, check whether the machine is qualified before delivery, to ensure that every machine for the customer is qualified artware selected carefully by Bright company.

width: 750px; height: 606.061px; margin-left: 0px; margin-top: 0px; Why choose us width: 750px; height: 3388.55px; margin-left: 0px; margin-top: 0px; Our Service

1.) Consultation service before, during,and after sales;
2.) Project planning and design service;
3.) Debugging of equipment until everything is functional;
4.) Management of equipments' long distance shipping from seller's factory to the named place by buyer;
5.) Training of equipment maintenance and operating personally;
6.) New production techniques and formulas;
7.) Provide 1 year complete warranty and life-time maintenance service.

width: 750px; height: 294px; margin-left: 0px; margin-top: 0px;Company&Customerwidth: 750px; height: 802.273px; margin-left: 0px; margin-top: 0px; width: 750px; height: 955px; margin-left: 0px; margin-top: 0px; width: 750px; height: 423px; margin-left: 0px; margin-top: 0px; FAQ

Q: Are you a trade company or a manufacturer?

A: we are a manufacturer, welcome to visit and check the machine to my factory.

Q: How long is your delivery time?

A: Generally it is 5-10 days if the goods are in stock. or it is 20-35 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?

A: 30% T/T in advance ,balance before shippment.

Q: How about the after-service?

A: We will send 1 engineer to the buyer’s factory for a 10-day period installation and training to the operators.

Q:do you supply any formula to buyer?

A:yes, we supply formula to buyer,


Why so many customers choose us :

1. Advantage technology
2. High quality material
3. Tight quality control
4. Accurate machine
5. 7 - 24 hours service

Packing &Delivery

1.Use anti-rust oil to wipe the equipment for breakfast cereal production line food extruder snacks corn ring making machinery

2.air cushion film packaging equipment for breakfast cereal production line food extruder snacks corn ring making machinery

3.with a wooden box for the final step of packaging for breakfast cereal production line food extruder snacks corn ring making machinery

width: 750px; height: 902px; margin-top: 0px; margin-left: 0px;

breakfast cereal production line food extruder snacks corn ring making machinery is a kind of breakfast with high nutritional value. usually use corn powder and other cereals as main raw material, through mixing, extruding, drying, baking, coating and cooling, to get crispy flakes. breakfast cereal production line food extruder snacks corn ring making machinery always service as breakfast cereal mixed with milk of coffee. But breakfast cereal production line food extruder snacks corn ring making machinery can also be a kind of leisure snacks. can also make other shapes of cereals such as rings, balls, chocos, curls etc. has adopted technology from America.

breakfast cereal production line food extruder snacks corn ring making machinery take corn flour as main raw material,breakfast cereal production line food extruder snacks corn ring making machinery's is very crispy after extruding,granulating,flaking, frying,seasoning. The outstanding characteristic of flakes is co-ntaining abundant compound carbohydrate and dietary fiber.Jinan Joysun Machinery Co., Ltd. can also add some trace elements and minerals. is very popular because of high nutritional value, delicious and convenience.
