Thin Profit Cereal Breakfast Food Making Machine Production Line Thin Profit Cereal Breakfast Food Making Machine Production Line Thin Profit Cereal Breakfast Food Making Machine Production Line

Thin Profit Cereal Breakfast Food Making Machine Production Line

Product Description Product Application Thin Profit Cereal Breakfast Food Making Machine Production Line Corn flakes/ breakfast cereals are one kind of crispy food,...
  • INFO@LDFOODMACHINE.COM | Get Latest Price
  • As final production line
  • Check with us
  • paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
  • Contact with us
  • China
  • Cereal Breakfast Food machine
  • CE ISO CNAS SGS TUV CCPIT
  • Cereal Breakfast Food machine

Product Description

Product Description

Product Application

Thin Profit Cereal Breakfast Food Making Machine Production Line

Corn flakes/ breakfast cereals are one kind of crispy food, with the advantages of hard to be steeped broken and strong grain taste. It is the crispy flake which is made from corn meal and the other grains powder. The production line includes mixing, extruding, flaking, drying, high temperature baking, flavoring and cooling. It can be eaten like snack and be eaten with milk or coffee as well. By changing molds and production process, this production line can make different shapes of puffed food. Such as ring, ball, flakes, star, letter etc.

SPECIFICATIONS FOR For Thin Profit Cereal Breakfast Food Making Machine Production Line
Name Model Output(KG/H) Installed power(KW) Power consumption(KW) Dimension(MM)
Mixer BF-| 25KG/Time 3 2 950*650*1060
Screw conveyor SL-| 100-200 0.75 0.5 3100(Pipeline)
Twin screw extruder TSE65-||| 100-150 35 20-25 2600*870*1950
Vibrating feeder ZS-2 100-300 0.25 0.2 1530*750*740
Drum type dryer 100-200 4.75 4 2420*780*1420
Air conveyor FS-0.75 100-300 0.75 0.5 Mating
Flaking machine(double staffs) YP-| 100-250 7.5 7 1200*900*1800
Dryer KX-3-5 100-300 27 18 5200*1300*2200
Hoister TS-| 100-300 0.55 0.5 1870*750*1460
High temperature inflated oven KL 100-250 78 70 4000*800*2400
Hoister and flavoring machine ZTTW 100-250 1.12 1 2300*600*1700
Single roller DGT 100-250 0.75 0.5 2420*780*1420
Oil spray 0.37 0.3 940*630*750
Cooling machine LQ-| 100-300 1.23 1 5300*1200*1500
width: 750px; height: 389.25px; margin-left: 0px; margin-top: 0px; width: 607.5px; height: 342px; margin-left: 0px; margin-top: 0px; width: 270.9px; height: 253.8px; margin-left: 0px; margin-top: 0px; width: 220.5px; height: 200.7px; margin-left: 0px; margin-top: 0px;

Main Features

1. We use the flaking material which is food grade stainless steel, the machine body is harmless; pressure distribution evenly to ensure the quality of tablet.
2. High-temperature oven can make the second expansion of semi-finished products, so that the product looks more beautiful shape, taste more crisp and refreshing.
3. After the flavoring machine, we set up a slopewit the oven instand of hoister. It will prevent the product stick from hoister, because the product full with sugar or oil.

4. Main body material: stainless steel
5. Screws quantity: 2
6. Screws material: 38CrMoAl
7. Rotating speed: adjustable
8. Temperature: adjustable
9. Self-cleaning function
10. Floor area: 220 square meters
11. Operator quantity: 2
12. Output: 100-500kg/h

Certificationswidth: 181.5px; height: 258.819px; margin-left: 0px; margin-top: 0px; width: 181.5px; height: 258.819px; margin-left: 0px; margin-top: 0px; width: 181.5px; height: 258.819px; margin-left: 0px; margin-top: 0px; width: 181.5px; height: 258.819px; margin-left: 0px; margin-top: 0px;Detailed Imageswidth: 371px; height: 336.55px; margin-left: 0px; margin-top: 0px;

Machine Parts

Name: High temperature inflated oven

Brand: Thin Profit Cereal Breakfast Food Making Machine Production Line

Original: China

High-temperature oven mainlymake the second expansion of semi-finished products

Machine Parts

Name: Dryer
Brand: Thin Profit Cereal Breakfast Food Making Machine Production Line
Original: China
Slopewit the oven will prevent the product stick from holster, because the product full with sugar or oil.

width: 351.9px; height: 198px; margin-left: 0px; margin-top: 0px; width: 243.9px; height: 223.2px; margin-left: 0px; margin-top: 0px;

Machine Parts

Name: Flaking machine
Brand: Thin Profit Cereal Breakfast Food Making Machine Production Line
Original: China
It mainly pressure distribution evenly to ensure the quality of tablet

Machine Parts

Name: Twin screw extruder
Brand: Thin Profit Cereal Breakfast Food Making Machine Production Line
Original: China
(1) Conditioner (option for small capacity lines, necessary for big capacity lines), used for pre-conditioning raw materials. (2) Twin-screw extruder, used for extruding and shaping.

width: 334.8px; height: 247.5px; margin-left: 0px; margin-top: 0px;Our Servicewidth: 363.6px; height: 162px; margin-left: 0px; margin-top: 0px; width: 371.7px; height: 244.8px; margin-left: 0px; margin-top: 0px;

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* The warranty period is one year.

* Our service is turn-key mode, which includes installment, debugging and train.
* Supply quick-wear part and general tool.
* Supply the basic formula of raw materials.
* We will provide drawings (CAD or Solid works) based on users’ workshop situation, and we can supply rationalization proposal

.

Packing & Deliverywidth: 371px; height: 344.659px; margin-left: 0px; margin-top: 0px;
Packaging
1. Inside package is plastic film, outside package is wooden or plywood cases, which is seaworthy.

2. We can supply fumigation package and certificate.

Company and customerwidth: 371px; height: 320.65px; margin-left: 0px; margin-top: 0px; width: 371px; height: 336.02px; margin-left: 0px; margin-top: 0px;

Thin Profit Cereal Breakfast Food Making Machine Production Line is a kind of breakfast with high nutritional value. usually use corn powder and other cereals as main raw material, through mixing, extruding, drying, baking, coating and cooling, to get crispy flakes. Thin Profit Cereal Breakfast Food Making Machine Production Line always service as breakfast cereal mixed with milk of coffee. But Thin Profit Cereal Breakfast Food Making Machine Production Line can also be a kind of leisure snacks. can also make other shapes of cereals such as rings, balls, chocos, curls etc. has adopted technology from America.

Thin Profit Cereal Breakfast Food Making Machine Production Line take corn flour as main raw material,Thin Profit Cereal Breakfast Food Making Machine Production Line's is very crispy after extruding,granulating,flaking, frying,seasoning. The outstanding characteristic of flakes is co-ntaining abundant compound carbohydrate and dietary fiber.Jinan Joysun Machinery Co., Ltd. can also add some trace elements and minerals. is very popular because of high nutritional value, delicious and convenience.
