Fruit and vegetable slicing strip cutting machine hard fruit and vegetable cutting machine

Fruit and vegetable slicing strip cutting machine hard fruit and vegetable cutting machine

Fruit and vegetable slicing strip cutting machine hard fruit and vegetable cutting machine 0086-18737189043 Product Description of root vegetable cutting...
  • Negotiation | Get Latest Price
  • 400*400*650mm
  • Within 5 working days
  • paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
  • 84
  • Original Fruit and vegetable slicing strip cutting machine hard fruit and vegetable cutting machine
  • HANCHUANG
  • CE ISO
  • HC-300B

Product Description

Fruit and vegetable slicing strip cutting machine hard fruit and vegetable cutting machine 0086-18737189043

Product Description of root vegetable cutting machine

The majority of user requirements should be, after my plant technical staff over the years to test and improve the latest development of new products - small multi-purpose vegetable machine came out. It is specially suitable for schools, factories and mines, military, canteens, pickles and lots of vegetables and vegetables. It is clean and hygienic and durable. It is suitable for use in schools, factories and mines, Greatly reduce the labor intensity, saving labor time, saving more than 80% of working hours.

Feature of potato cutting machine

1, slice processing, the thickness (1-10mm) adjustable.

2, shredding processing, the existing thickness of two specifications 3.5mm, 2.5mm

3, the production efficiency depending on the situation of vegetables, under normal circumstances, an hour processing 300 kg, such as continuous mass production, the efficiency is higher.

Parameters of sweet potato slicing machine

The operation adjustment of potato slicing machine

The machine blade consists of a fixed slicer and a replaceable shredder. Slices knife work alone, can be cut into pieces, shredded processing, installed on the shredded knife group, can be processed into silk, the cut into the wire, once again into the processing, you can get ding that is trapped. Diced processing, the installation of cutting knife group, a processing into a square, the square into the processing again, you can get the box.

blade replacement adjustment

Slice processing, the eccentric operation handle on the side of the butterfly nut release, pull the handle to the handle, the slices thinning, the reverse film thicker, replace the knife group before the butterfly nut release, pull the handle to the most , To talk about the knife group to be replaced after the push in place, tighten the top of the knob, and then move the handle outside the pull, until the bottom of the activities to close the end of the group, and then tighten the butterfly nut. (Note: each time you replace the blade, should be in this order)

maintenance and precautions

1, before use, should adhere to the direction of rotation and the marked heart is consistent, if not consistent, you need to adjust the point source.

2, before use, should be in the ground signs, then secure the line, to ensure personal safety.

3, remember to wash the dishes, excluding non-vegetable hard objects (such as metal, brick, etc.), so as to avoid damage to the blade.

4, for a long time when not in use, the blade should be removed, remove the impurities between them, and oil storage.

5, the machine uses centrifugal force to promote the work of the vegetables, so hand operation with the speed when the speed is not appropriate, not reach the desired efficiency.

Special Note: If the blade accidentally broken, should immediately stop and find the broken part, so as not to be mixed into the food into the food. (Can be used to find the magnet, must be part of the processing must be thrown away. Blade damage phenomenon, cut the individual wire thicker or a knife phenomenon.) Welcome new and old users to make valuable comments.

Application of root vegetable/ fruit cutting machine

the machine performance can be cut, sliced, you can also cut, cut, cut and so on. This machine is suitable for slicing ginger and garlic slices, and can be used for hawthorn, potatoes, radish, onion, water chestnuts, eggplant, cucumber, cabbage, minced garlic and pickles. Thickness can be adjusted, the use of mechanical principles of the design of the blade shape to make slices more light, smooth surface, sheet neat, low damage rate, high production efficiency.

Picture of vegetable and fruit slicer strip cutter machine

Packaging & Shipping

1. Testing Machine before package

2. Package : Inside plastic bag, outside wooden case.

3. Shipping: By sea, By air.

By sea: if customer not urgently the machine, we advice by sea, even though by sea took time is long, but by sea reduce much money about the freight, and it is good for customer if the machine is heavy and big size.

By air: it is faster than by sea, but its freight is higher much than by sea, so this kind of type always suggest for light, small size and urgently demand machine.

Our Services

Pre-sale service
1.Related machines’s technical parameter will be supplied to customer.
2.According to customer’s factory size, factory layout can be provided in advance.

3. According to customer’s material cost, general formulation can be prepared well.
4.Special machine can be supplied as customer’s request.
5.Professional Advice about Market, machines, processing , materials, packing can be supplied
6. Suggesting professional ship agent or helping book ship as customer request.

After sale service:

1.Allocation chart as the buyer’s request will be supplied.
2.Operation manual will be supplied after shipment.
3.One year warrantee, life time maintenance with cost price.
4.Free easy broken spare parts will be sent with container .
5.First installation can be done by engineer.
6.Training workers in customer’s factory.

Fruit and vegetable slicing strip cutting machine hard fruit and vegetable cutting machine is our company's self-developed Fruit and vegetable slicing strip cutting machine hard fruit and vegetable cutting machine according to European and American equipment, Fruit and vegetable slicing strip cutting machine hard fruit and vegetable cutting machine has a high degree of automation, stability, simple operation, high yield, short process time and other characteristics, and effectively improve the various defects in the original tradition. Widely used in all kinds of baby rice noodles, sesame paste, walnut paste products, is a new and efficient . produced foods with unique shape, many flavors and colors, and scientific scientific nutrition, has a reasonable structural design, screw is a special material, has a fast self-cleaning function, high machine stability, easy to learn, accurate parameters Control can ensure that the products produced have the same shape, taste and color.
Jinan Joysun Machinery Co., Ltd. was established in 1993. Jinan Joysun Machinery Co., Ltd. is located in Shandong Province with a registered capital of 2 million RMB and covers an area of 9,800 square meters. Jinan Joysun Machinery Co., Ltd. is a professional food machinery manufacturing company integrating research and development, professional production, direct sales and after-sales services. We took the lead in awarding and passing the quality standards of commercial products in Shandong Province, and successfully passed ISO9001:2008 international quality management system certification, and exported to the European Union's CE safety certification, BV certification, third-party certification. Now we have successfully obtained the trademark.
