Commercial kelloggs corn flakes and breakfast cereal production machine
Brief introduction of the corn flakes and nutritional cereal processing line:
Corn flakes is a kind of crisp food, used grain flour as the basic raw material. By the processing line it is processed to
flakes instant food which is pressed by particle. The outstanding feature is that it is rich in composite carbon compounds
and dietary fiber. At the same time, corn flakes can not only strengthen much trace element, such as vitamins and minerals,
but also add cocoa and sugar,such as honey,maltose, etc. After adding into coffee,milk,yogurt,or functional drinks, we
can directly eat it. Children can also eat it as sweet and brittle leisure Kellooggs corn flakes /coco rings /breakfast cereal processing line with CE ISO certificated.
1. Raw Materials: Main corn Powder and Other Cereals Powder
2. Products: All kinds of snacks with different shapes and types.
3. Capacity: 60-80 KG/H,100-150KG/H ,200 -250KG/H,300-350 KG/H
4. Flow Chart: Mixing —Extruding —Flaking —Drying — Baking —Coating —Baking —Cooling
5. Voltage: Three phases: 380V/50HZ, Single phase: 220V/50HZ,
also can make it according to customers' local voltage of different countries
6. Machines Materials: All the machines are made by food grade stainless steel.
Technical Parameters of Breakfast Cereal Production Line :
|Model||Installed power||Power consumption||Throughput||Dimension|
|DG32-II processing line||135KW||101KW||60-80kg/h||45X2.8X2.7M|
|DG52-II processing line||210kw||168KW||100-150kg/h||54.7X2.8X2.7M|
|DG75-II processing line||292KW||219KW||200-250kg/h||64.2X3.2X3.1M|
|DG75-II B processing line||342KW||256KW||300-350kg/h||69X3.3X3.8M|
CAD drawing of Corn Flakes and Breakfast cereal production line (Example:300-350kg/h):
Brief introductions of single machines of the corn flakes and cereal processing line:
1.Flour mixer : to mix various raw materil evenly.
2.Screw conveyor : to convey raw material to extrude
3.Twin/Double screw extruder :to extruder and cook the raw material into different shapes breakfast cereal
4.Water injector: to inject water on the producing process.
5.Vibrating cooler: to spread the products and cool it quickly.
6.Air conveyor: to convey the food to the next machine
7.Flakes presser: to press the particles into thin flakes (its size of flakes can be adjusted)
8.Higher vibrating cooler: to spread the flakes and sancks food and cool it quickly.
9.Belt drying oven: to dry snacks food by circulating belt.
10.Belt conveyor: to elevate the snacks food to the next machine
11.High temperature toaster: to use hot air to dry the snacks food.
12.Flavoring machine: to spray flour ,sugar oil and other seansons on the food to get decilious food.
13.Extending drying oven: to dry the corn flakes after it being coated sugar.
14.Cooling conveyor: to cool food.
Breakfast cereal and corn flakes samples :
Main machines for corn flakes and breakfast cereal production line:
Twin screw extruder with different type:
Drying oven with steam type electricity type diesel type gas type hot oil version
Higher capacity flakes presser:
High temperature drying roaster:
Corn flakes/Coco balls/Coco rings snacks food machines demonstrating and producing workshop:
Warmly welcome to our factory at any time to check it
Packaging and shipping:
About us :Kellooggs corn flakes /coco rings /breakfast cereal processing line with CE ISO certificated machinery co.,ltd in China:
We: Kellooggs corn flakes /coco rings /breakfast cereal processing line with CE ISO certificated machinery co.,ltd located in Jinan ,Shandong Province ,China, is the professional manufacturer of
Kellooggs corn flakes /coco rings /breakfast cereal processing line with CE ISO certificated processing machinery.We specialize in this field for may years ,not only can supply with the entire machiner
design,but also can modify the production line to meet client's demand.All kinds of patents , proprietary technology ,
breakthrough and certificated .
There is a testing center in our factory which combined experiments,dmonstration andtrainingin one facility.We also
can test new technical experiments according to customer requirements .
Our extrusion systems are widely used in:puffed Kellooggs corn flakes /coco rings /breakfast cereal processing line with CE ISO certificated,breakfast cereals,corn flakes ,nutritional artificaila rice,
textured or fibre protein food,pet food,aquatic feed,modified starch,bread crumbs and other Kellooggs corn flakes /coco rings /breakfast cereal processing line with CE ISO certificated.
If you are interested in us,pls no hestitate to contact us:
Hot sale snacks food production line
|2||3d&2d snack pellets production line|
|3||Artificial rice production line|
|4||TVP/TSP Textured soy protein production line|
|5||Corn puffed snacks food production line|
|8||Cheetos/Kurkure production line|
|9||Caramel popcorn production line|
|10||Bread crumbs production line|
|11||Pet food production line|
Kellooggs corn flakes /coco rings /breakfast cereal processing line with CE ISO certificated is a kind of breakfast with high nutritional value. usually use corn powder and other cereals as main raw material, through mixing, extruding, drying, baking, coating and cooling, to get crispy flakes. Kellooggs corn flakes /coco rings /breakfast cereal processing line with CE ISO certificated always service as breakfast cereal mixed with milk of coffee. But Kellooggs corn flakes /coco rings /breakfast cereal processing line with CE ISO certificated can also be a kind of leisure snacks. can also make other shapes of cereals such as rings, balls, chocos, curls etc. has adopted technology from America.
Kellooggs corn flakes /coco rings /breakfast cereal processing line with CE ISO certificated take corn flour as main raw material,Kellooggs corn flakes /coco rings /breakfast cereal processing line with CE ISO certificated's is very crispy after extruding,granulating,flaking, frying,seasoning. The outstanding characteristic of flakes is co-ntaining abundant compound carbohydrate and dietary fiber.Jinan Joysun Machinery Co., Ltd. can also add some trace elements and minerals. is very popular because of high nutritional value, delicious and convenience.
