Product Description

Factory hot sale promotion automatic pine nut peeling machine

Product Description

Introduction of automatic pine nut peeling machine:

This machine is designed to dehull, remove shells, separate and reseparate your product.

The equipment features low electricity consumption, compact structure, small area occupation, low damage of seeds and kernels, automatic feeding of unhulled seeds, simple maintenance. It is recognized to be one of the most optimum equipment for sunflower seeds , pine nuts ,watermelon and so on dehulling and separating in the world.

Features of automatic pine nut peeling machine:

firstseeds will be lifted up by bucket elevator and then will go into 4 dehullers respectively for dehulling.After dehulling, the mixture of shells, seeds and kernels will go into shell-seed-kernel separator for sorting out shells from the mixture, and then all the shells will be discharged through cyclone and the screw discharger.After removing shells through the top screen, the mixture of seeds and kernels will go into seed-kernel separator to separate the kernels from seeds. The initial kernels separated from seeds will move forward to the first re-separator, and the undehulled seeds will go back to dehullers through bucket elevator for re-hulling. and then the mixture of seeds and kernels after initial separating will go into second reseparator for second time seed-kernel’s reseparating works. And the unhulled seeds will go back to the bucket elevator,

through which entering the 4 dehullers for re-hulling. and again, the mixture of seeds and kernels after second separating will go into the third reseparator for the third time seed-kernel’s reseparating works. And the unhulled seeds with small amount of kernels will go back to the first inlet of the materials back-flowing system, and back to the seed-kernel separator for re-separating elevated by penumatic suction. And finally sunflower kernels will be ready at the terminal.

  1. 1. Power supply: Three-phase 380V 50 Hz, and the voltage fluctuation range is in-between±10%.
  2. 2. The room temperature should be controlled within the range of -10℃ to 50℃. The frequency inverter could be damaged and the motor can not run normally if the room temperature is under -10℃.
  3. 3. Workshop shall be well leveled floor, clean and tidy, all the passage shall be free of obstacles. Of course the workshop shall be well covered and free from rain or snow.
  4. 4. this equipment is no side effects at all to environment, no harmful gas or liquid emission.

Technical parameter:

Power 13.23kw(380v 3phase 50Hz)
Input capacity 0.6-1.0mt/hour
% of whole kernels 90% approx.(broken kernel is less than 1/2 of the whole one)
% of inshell in kernels 2-5% approx.( varies with raw materials)
Space occupied: 4.0m*3.3m*5.3m
Operator 2 workers

Pictures of automatic pine nut peeling machine:

Packaging & Shipping

Pre-sale:

1. Suggest to client suitable raw material, final product capacity.

2. Introduce machine's structure and features in detail, explain the price component.

3. answer client concerned questions.

After-sale:

1. Start production as soon as receiving down payment.

2. Send photos of machine in manufacturing and finished photos to client, for your better learn about the machine's condition.

3. Delivery machine in time, taking photos during loading, so you can "remote monitoring" your goods.

4. Documents and certificate available in time.

5. Manual documents available. Engineer can be sent to client site for installation instruction.
