Home >  Auto Packing System >  Hot selling, fully automatic large sized licorice watermelon seeds packing machine, with multihead weigher packing system
Hot selling, fully automatic large sized licorice watermelon seeds packing machine, with multihead weigher packing system Hot selling, fully automatic large sized licorice watermelon seeds packing machine, with multihead weigher packing system Hot selling, fully automatic large sized licorice watermelon seeds packing machine, with multihead weigher packing system

Hot selling, fully automatic large sized licorice watermelon seeds packing machine, with multihead weigher packing system

Video In Hot selling, fully automatic large sized licorice watermelon seeds packing machine, with multihead weigher packing system Woking Video Link in Hot selling, fully...
  • INFO@LDFOODMACHINE.COM | Get Latest Price
  • 1430x1200x1700mm
  • Within 5 working days
  • paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
  • Contact with us
  • China
  • Auto Packing System
  • CE Certification
  • Auto Packing System

Product Description

Video In Hot selling, fully automatic large sized licorice watermelon seeds packing machine, with multihead weigher packing system

Woking Video Link in Hot selling, fully automatic large sized licorice watermelon seeds packing machine, with multihead weigher packing system :

https://youtu.be/inZHtvbG7eU

https://youtu.be/V1K2_C6n0oU

Detailed Images

1. Machine drawing:

2. Packing machine Drawing :

Product Uses

granulated sugar packing machine, sugar bags packing machine, packing machine for sugar

Suitable for packing all kinds of granules food, such as peanut, sunflower seeds, sesame seeds, nuts, pumpkin seeds, watermelon seeds, beans, rice, wheat, corn and other grain food.

display: block; margin-left: auto; margin-right: auto;

Product Description

Technical parameter:

Model GD-420D GD-520D GD-620D GD-720D GD-820D
Max Roll film width 420mm 520mm 620mm 720mm 820mm
Bag making length 80-300mm 80-350mm 80-350mm 100-500mm 100-600mm
Bag making width 60-200mm 80-250mm 100-250mm 180-350mm 180-400mm
Packing speed 5-80bags.min 5-50bags/min 5-40bags/min 5-35bags/min 5-30bags/min
Max Filling volume 1500ml 2000ml 3000ml 4000ml 6000ml
Air consumption 0.65mpa
0.65mpa 0.65mpa 0.65mpa 0.65mpa
Gas consumption 3m³/min 3m³/min 4m³/min 4m³/min 4m³/min
Power 220v 50/60hz 2.2kw 220V 50/60hz 220v 50/60hz 2kw 220v 50/60hz 3kw 220v 50hz 5kw
Weight 650kg 700kg 750kg 800kg 900kg
Dimension 1430x1200x1700mm 1550x1200x1800mm 1780x1300x1950mm 1800x1310x1950mm 1980x1350x2150mm

Optional fittings:

Machine Parts Photos

1. 10 Heads weigher :

display: block; margin-left: auto; margin-right: auto;

(1) Application :

It is suitable for weighing of granule, slice, roll or irregular shape products such as candy, sunflower seed, potato chip, happy fruit, peanut, jelly, freezing rice dumpling, biscuit, chocolate, nut, pet food, puffed food, small metal parts and plastic parts, etc.

(2).Features

* Program recovery function can reduce operation failure.

* All the hoppers can be opened make cleaning easy and quick.

* The weight hopper can be preset to open in order (staggered) to avoid lockage with puffy or problem products.

* IP65 waterproof and dustproof design. It's easy to clean and maintain.

* The function of measurement by counting pieces or components t satisfy your various requirements.

(3).Technical parameter :

Weighing range

10~1000g

Weighing Accuracy

0.2-1.5g

Max. Weighing speed

45bags/min

Hopper Volume

1.6L

Control Panel

7.0 LCD keypad screen 10.4"touch screen

Driving System

Step motor

Power Requirements

1. 10 Heads weigher :

Packing Dimension (mm)

1700(L) x 1200(W) x 1300(H)

Gross WGT

480KG

2.Supporting platform:

display: block; margin-left: auto; margin-right: auto;

Features:

* The plane is about 4 square meters, it have safety barriers and stairs.

* Dimension(mm):1800(L)*1800(W)* 2220(H)


3. Z type Elevator:

display: block; margin-left: auto; margin-right: auto;

Features:

The conveyer is applicable for vertical lifting of grain material in departments such as corn, food, fodder andchemical industry, etc. For the lifting machine, the hopper is driven by the chains to lift. It's used for vertical feeding of grain or small block material. It has advantages of large lifting quantity and highness

Specification:

The highness of lifting 3m -10m ( it can adjust ccording to customer's requirement.)

lifting quantity: 12cubic meter/hour

power 550w

voltage 380v

Specification customized; material: carbon steel plastic spray or stainless steel; the part contacting with food is food grade plastic.

4.Conveyor :

display: block; margin-left: auto; margin-right: auto;

The machine can send the packed finished bag to after-package detecting device or packing platform.

* Feeding speed 30m\minute

*Dimension 2110×340×500mm

* Power: 45W, 220V

Packaging & Shipping

Our Services

1. Manules/Videos of machine installation, adjusting, setting, maintenance are available for you.

2. If any problems happend and you can not find out the solutions, Telecom or Online face to face communication available 24 hours;

3. Golden engineers & technician are available send to your countries for services if you agree pay the expenditure;

4. Warranty: 2 years (Electric accessories ) and free life time maintenance (Excluding freight) ;

5. Goldsen has an independent team for after-sale service. any emermancy please call the saleman or our after-sale's manager .

Company Information

With more than 20 years expertise and experience.

Embrace flexibility and professionalism.

No lowest price but always value for money.

We treat our staffs and suppliers as respectful partners.

We keep stock of electronic components, touch displays, motors, etc. ready for immediate delivery.

Provide customized services for special orders according to specifications.

Hot selling, fully automatic large sized licorice watermelon seeds packing machine, with multihead weigher packing system is now a general-purpose model DL3000-100 single screw, is mainly used for the production of a variety of pasta, fried foods, rice noodles, pasta, pasta and other products, stable output, simple and convenient operation. 3000 is the length of the screw and 100 is the diameter of the screw.
Hot selling, fully automatic large sized licorice watermelon seeds packing machine, with multihead weigher packing system consists of feeding system, extrusion system, rotary cutting system, heating system, transmission system and control system. The use of advanced screw extrusion technology, the use of high temperature and high pressure material curing and expansion molding, one-time completion. The host adopts variable frequency speed regulation to ensure the stability of the production process. Product color, variety, appearance, natural and realistic, delicate texture, raw materials are widely used of .
