Stone Impact Crusher, PF Rock Impact Crusher, Efficient and Strong Coarse crusher Stone Impact Crusher, PF Rock Impact Crusher, Efficient and Strong Coarse crusher Stone Impact Crusher, PF Rock Impact Crusher, Efficient and Strong Coarse crusher

Stone Impact Crusher, PF Rock Impact Crusher, Efficient and Strong Coarse crusher

Introduction of Impact crusher The impact crusher is suitable for the materials with the side length less than 100-500mm. Compared with general crusher, it not only havs...
  • INFO@LDFOODMACHINE.COM | Get Latest Price
  • 2370x1700x2390
  • Within 5 working days
  • paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
  • Contact with us
  • China
  • Peanut Crusher Machine
  • CE/ISO9001:2000
  • Peanut Crusher Machine

Product Description

Introduction of Impact crusher
The impact crusher is suitable for the materials with the side length less than 100-500mm. Compared with general crusher, it not only havs advantages of large crushing ratio, even size without phenomenon of over-crushing, low energy consumption, easy maintenance, it also has wide range of adjustable size and a strong ability of selective crushing. Moreover, it is widely used mineral, chemical, cement, building, refractory liner, and ceramic industries, mainly suitable for medium and fine crushing, such as the ore, rock and slag with mid-hardness. It can reach the high compression strength of 350MPa. It has the features of high crushing ratio, high capacity, etc. Colombia stone breaking impact crusher/rock impact crusher/small impact crusher machine

Work Principle of Impact crusher
During operation, fine impact crusher is driven by the motor which makes the rotor revolve in high speed. When the materials are sent into the first cavity, it will be impacted by the hammer; and then be smashed into the second fine cavity for crushing,

finally it is discharged out. Colombia stone breaking impact crusher/rock impact crusher/small impact crusher machine

Operation principles of Impact Crusher
The impact crusher crushes materials with impact force. It consists of rear case, impact plate,impact rack, scale board, feed

opening, back frame, blow bar, rotor and other components.

When working ,the motor drives the rotor rotate in high speed, when the ores enter into the cavity, the blow bar will impact them

with high speed rotary, and then throw them to the first impact plate. As the action of the impact force, the material will be

crushed again and rebounded to the blow bar. Repeat the above process, the material will be threw to the second blow bar for

further crushing, when the size is smaller than the gap between blow bar and impact plate, the end products will be discharged from the lower parts. Moreover, adjust the gap will change the size and shape of the end products. Colombia stone breaking impact crusher/rock impact crusher/small impact crusher machine

Features and Benefits of Impact Crusher
1.Big crushing ratio, high-efficiency , low energy;
2.Special structure, no-board connection;
3.High chrome hammer, unique impact plate;
4.Good product with cubical shape , no tension and crack, adjustable crushing ,simplified crushing process;
5.Easy maintenance, reliable operation.

Technical Parameters of Impact Crusher

Model

Specifications
(mm)

Feed opening(mm)

Max feeding side length
(mm)

Capacity
(t/h)

Power
(kw)

Total weight
(t)

Dimensions
(LxWxH)
(mm)

PF-0607

644x740

320x770

100

10-20

30

4

1500x1450x1500

PF-0807

850x700

400x730

300

15-30

30-45

8.13

1900x1850x1500

PF-1007

1000x700

400x730

300

30-70

45

12

2330x1660x2300

PF-1010

1000x1050

400x1080

350

50-90

55

15

2370x1700x2390

PF-1210

1250x1050

400x1080

350

70-130

110

17.7

2680x2160x2800

PF-1214

1250x1400

400x1430

350

100-180

132

22.4

2650x2460x2800

PF-1315

1320x1500

860x1520

500

130-250

220

27

3180x2720x2620

PF-1320

1320x2000

860x2030

500

160-350

300

30

3200x3790x3100

Training & service

Training is FREE to every customer. Whenever you need us, for installation, maintenance, or proper use of our company machines, we will be right there for you. In addition, we provide 2-years warranty to make sure your machine runs consistently. We always keep certain inventory level of spare parts, which means the replacements can be shipped to you right away.

Why choose Yufeng Company

We are manufacturer in Zhengzhou, which serves as the largest base of Chinese industrial technology, and the busiest container port in the world. The competition in this city is severe, only companies with ending technology, stable workforce, and effective cost management could survive. With 25 years of efforts and innovation,our company is now a Stone Impact Crusher, PF Rock Impact Crusher, Efficient and Strong Coarse crusher brand in China.

Affordable, high-quality machines. Our highly competitive price relies upon our ability to minimize our costs, of which our

competitors don’t.

1. We are factory(NOT Dealer)

2. We own our factory & Land (NOT Rent)

3. Staff reside in factory(Stable Workforce)

Producing high-quality and reliable machines is always our first priority, because we know that our success depends entirely on the satisfaction of our customers. We never give-up quality to save cost, instead we manufacture our machines to supply you the best need.

ZHENGZHOU YUFENG HEAVY MACHINERY CO., LTD

We can design flowchart and layout according to customers' need.If you want to learn more information,please contact us any time.
Whatsapp/Wechat/Viber 0086 13526817088

...

uses the deffatted soya/peanut flour as the raw materials. By high temperature and presser,Jinan Joysun Machinery Co., Ltd. the materials can reorgnized and shaped into different shapes by Stone Impact Crusher, PF Rock Impact Crusher, Efficient and Strong Coarse crusher , such as pipe, stick,ball, pellets, pillow and so on. As the line make more concentrated and healthy protein, has become the most popular line in all the world.

Stone Impact Crusher, PF Rock Impact Crusher, Efficient and Strong Coarse crusher relies on additional energy being supplied that’s preferentially absorbed by the solvents in the process to enhance evaporation Jinan Joysun Machinery Co., Ltd. . are a form of electromagnetic energy (300 Mhz–300 GHz), Stone Impact Crusher, PF Rock Impact Crusher, Efficient and Strong Coarse crusher generated by magnetrons under the combined force of perpendicular electric and magnetic fields by .

This mixer Stone Impact Crusher, PF Rock Impact Crusher, Efficient and Strong Coarse crusher is three layers and including cooling, heating and heating insulation. is mainly suitable for preparation of foodstuff.Jinan Joysun Machinery Co., Ltd. pharmacy and liquid detergents (such as liquid soap,cleanser essence, shampoo and shower cream etc.).Stone Impact Crusher, PF Rock Impact Crusher, Efficient and Strong Coarse crusher Integrating blending, homogenizing dispersing, heating and cooling etc functions, the reacting machine is an ideal device for liquid preparation in various factories.
