Product Description
- agricultural machinery electrical 4 blades peanut crusher machine
The usage of peanut crusher machine
peanut crusher machine is used cutting all kinds of corn stalks, wheat stalks, straws, crop straw and pasture. The processing material can feed cow, sheep, horse these animal, meanwhile, peanut crusher machine also can handle branches, cotton stalk and tree bark, can be used in Straw power generation, ethanol, papermaking and man-made board, etc.
The benefits of peanut crusher machine
1. Tough three-blade cutter, there is Two-way adjusting nut between blade disk and main shaft.
it is more easier to adjust gap between blades.
2.advanced feeding structure, special feeding grass device (was national patent product ), automatic feeding, high efficiency.
3.the knife has a safty guide device, avoid accident.
4.unique speed gear box structure, easy to adjust the grass length, reliable sealing box, good lubrication.
5. It has widely use range and can be applied to processing different crop straw and materials.
6. Cutter with high-quality steel, with a special refining process, supper wear-resistant, using high strength bolts, safety and reliability.
7. It is the necessary mechanical equipment for the vast rural and medium-sized feed mill , can also used for agriculture, pasture and paper mills, medicinal materials factory .
8. Low noise,simple construction,working stability,competitive price, high quality ,easy to operate.
Technical parameter of peanut crusher machine
Model |
9Z-4C |
9Z-4C(pull type) |
||
Main power |
Motor |
Power (kw) |
5.5 |
|
|
|
Rotating speed (r/min) |
1440 |
|
|
Diesel (Tractor)
|
Drive system |
Belt drive |
Pto shaft |
|
|
Horsepower (HP) |
12-15 |
|
|
|
Speed of PTO shaft (r/min) |
|
540 |
|
|
tractor hitch |
|
Pull type |
Dimension |
Shipping size(L*W*H)mm |
630*1010*1300 |
||
|
Using size(L*W*H)mm |
1737*1575*2315 |
2690*1210*2390 |
|
Weight (kg) |
280 |
340 |
||
Speed of cutter disk(r/min) |
800 |
800 |
||
Blade (pieces) |
4 pieces |
|||
Pto shaft keys |
|
6 |
||
V-belt |
B1800 three branches |
B1350 three branches |
||
Capacity of 9Z-4C and 9Z-4C(pull type) | ||||
Raw material |
Capacity |
|||
Green corn straw (78% moisture) |
4 t/h |
|||
Dry corn straw (17% moisture) |
1.6 t/h |
|||
Dry straw (17%) |
1.3 t/h |
|||
Dry wheat straw (17%) |
1 t/h |
|||
Dry alfalfa (20%) |
1.5 t/h |
|||
Chopping Length (mm) |
17mm; 22mm; 34mm; 44mm |
|||
Product distance (m) |
4-6m |
Model |
9Z-6A |
9Z-6A (pull type) |
|||
Main power |
Motor |
Power (kw) |
7.5 |
|
|
Rotating speed (r/min) |
1440 |
||||
Diesel (Tractor)
|
Drive system |
Belt drive |
Pto shaft |
||
Horsepower (HP) |
15-20 |
||||
Speed of PTO shaft (r/min) |
|
540 |
|||
tractor hitch |
|
Pull type |
|||
Dimension |
Shipping size(L*W*H)mm |
755*1393*1585 |
|||
Using size(L*W*H)mm |
2147*1600*2756 |
3110*1500*2866 |
|||
Weight (kg) |
400 |
460 |
|||
Speed of cutter disk(r/min) |
650 |
650 |
|||
Blade (pieces) |
3-4 pieces |
||||
Pto shaft keys |
|
6 |
|||
V-belt |
B2150 three branches |
B1400 three branches |
|||
Capacity of 9Z-6A and 9Z-6A (pull type) | |||||
Raw material |
Capacity |
||||
Green corn straw (78% moisture) |
6 t/h |
||||
Dry corn straw (17% moisture) |
2 t/h |
||||
Dry straw (17%) |
2 t/h |
||||
Dry wheat straw (17%) |
1.5 t/h |
||||
Dry alfalfa (20%) |
2.5 t/h |
||||
Chopping Length (mm) |
2 blades |
18mm,27mm,38mm,53mm |
|||
3 blades |
12mm,18mm,25mm,35mm |
||||
4 blades |
9mm,14mm,19mm,27mm |
||||
Product distance (m) |
5-8m |
Model |
9Z-9A |
9Z-9A (pull type) |
|||
Main power |
Motor |
Power (kw) |
15 |
|
|
Rotating speed (r/min) |
1440 |
||||
Diesel (Tractor)
|
Drive system |
Belt drive |
Pto shaft |
||
Horsepower (HP) |
25 |
25-50 |
|||
Speed of PTO shaft (r/min) |
|
540 |
|||
tractor hitch |
|
Pull type |
|||
Dimension |
Shipping size(L*W*H)mm |
2620*1720*1850 |
2735*1800*1960 |
||
Using size(L*W*H)mm |
2735*1800*1960 |
3510*1800*4210 |
|||
Weight (kg) |
880 |
880 |
|||
Speed of cutter disk(r/min) |
500 |
||||
Blade (pieces) |
3 pieces |
||||
Pto shaft keys |
|
8 |
|||
V-belt |
B3000 5 branches |
B1900 4 branches |
|||
Capacity of 9Z-9A and 9Z-9A (pull type) | |||||
Raw material |
Capacity |
||||
Green corn straw (78% moisture) |
9 t/h |
||||
Dry corn straw (17% moisture) |
3.5 t/h |
||||
Dry straw (17%) |
4 t/h |
||||
Dry wheat straw (17%) |
3 t/h |
||||
Dry alfalfa (20%) |
3.5 t/h |
||||
Chopping Length (mm) |
3 blades |
12mm; 18mm; 25mm; 35mm |
|||
Product distance (m) |
10-15m |
Model |
9Z-30 |
||||
Main power |
Motor |
Main Power (kw) |
30 |
||
Rotating speed (r/min) |
1470 |
||||
Feeding power (kw) |
4 |
||||
Dimension |
Shipping size(L*W*H)mm |
3630*2070*2810 |
|||
Using size(L*W*H)mm |
4290*2510*4510 |
||||
Weight (kg) |
2300 |
||||
Speed of cutter disk(r/min) |
450 |
||||
Blade (pieces) |
3 pieces |
||||
Driven system |
V-belt drive |
||||
V-belt |
B3050 5 branches |
||||
Capacity of 9Z-30 | |||||
Raw material |
Capacity |
||||
Green corn straw (78% moisture) |
30 t/h |
||||
Dry corn straw (17% moisture) |
12 t/h |
||||
Dry straw (17%) |
10 t/h |
||||
Dry wheat straw (17%) |
12 t/h |
||||
Dry alfalfa (20%) |
12 t/h |
||||
Cotton stalk (17%) |
10 t/h |
||||
Chopping Length (mm) |
3 blades |
18mm; 27mm; 41mm;64mm |
|||
Product distance (m) |
10-15m |
Model |
9Z-2.5 |
||||
Main power |
Motor |
Power (kw) |
4 |
||
Rotating speed (r/min) |
1440 |
||||
Motor pulley |
Φ105mm |
||||
diesel tractor Or Agricultural tricycle |
Driven system |
Belt drive |
|||
Horsepower (HP) |
8-12 |
||||
Diesel pulley |
Φ135mm |
||||
Dimension |
Shipping size(L*W*H)mm |
510*982*1050 |
|||
Using size(L*W*H)mm |
1230*1150*1695 |
||||
Weight (kg) |
138 |
||||
Speed of cutter disk(r/min) |
800 |
||||
V-belt |
B1650 5 branches |
||||
Capacity of 9Z-2.5 | |||||
Raw material |
Capacity |
||||
Green corn straw (78% moisture) |
2.5 t/h |
||||
Dry corn straw (17% moisture) |
1 t/h |
||||
Dry straw (17%) |
1 t/h |
||||
Dry wheat straw (17%) |
0.6 t/h |
||||
Dry alfalfa (20%) |
1.2 t/h |
||||
Chopping Length (mm) |
2 blades |
22mm,52mm |
|||
3 blades |
15mm,35mm |
||||
4 blades |
11mm,26mm |
The pictures of peanut crusher machine
details of packaging of peanut crusher machine
1. Wooden or metal case according to specific size of each equipment, we twine thick plastic coating for each machine.
2. Tight the equipment in the truck without space to ensure no rubbing during the transportation.
details of shipping of peanut crusher machine
1. Port: Qingdao / Tianjin
2. Payment Terms: L/C T/T
3. Delivery Time: 20 Days After Receiving the Deposit
