Home >  Peanut Crusher Machine >  Factory Sell Small Multifunctional Wood Waste Hammer Mill/Hammer Crusher
Factory Sell Small Multifunctional Wood Waste Hammer Mill/Hammer Crusher Factory Sell Small Multifunctional Wood Waste Hammer Mill/Hammer Crusher Factory Sell Small Multifunctional Wood Waste Hammer Mill/Hammer Crusher

Factory Sell Small Multifunctional Wood Waste Hammer Mill/Hammer Crusher

Wood Waste Hammer Mill/Hammer Crusher Introduction of Wood Waste Hammer...
  • INFO@LDFOODMACHINE.COM | Get Latest Price
  • 1700*1000*1100mm
  • Within 5 working days
  • paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
  • Contact with us
  • China
  • Peanut Crusher Machine
  • CE, ISO9001 certificate
  • Peanut Crusher Machine

Product Description

Wood Waste Hammer Mill/Hammer Crusher

Introduction of Wood Waste Hammer Mill/Crusher:


1,Wood Waste Hammer Mill/Crusher can be used by two methods, positive pressure and negative pressure. The picture showed to you is negative pressure use whicj match with fan blower, cyclone, air lock, electricity control cabinet and so on. This grinding system can use bags to collect dust in the grinding process.

2,Wood Waste Hammer Mill/Crusher is multifunctional, mainly used to crushe raw material with small diameter such as corn straw, wheat straw, corn cop, tree twigs ,etc. Fineness can be 1-20mm.

3,Wood Waste Hammer Mill/Hammer Crusher key spare parts such as hammer blades are alloy steel material, crushing system is setady, wear resistance, and function is good.

4,Wood Waste Hammer Mill/Hammer Crusher is one of models adopts water cooling structure, reducing a lot damage to spare parts due to high temperature after working long time, now small wood hammer mill is mainly used in wood factory, feed factory, cultivation factory, Chemical industry and so on.

5. Wood Waste Hammer Mill/Hammer Crusher raw material should be not too wet, if moisture kept between 15-20%, then will be the best. Low moisture, then per hour capacity is more higher, or will be lower.

6,Wood Waste Hammer Mill/Hammer Crusher has work with cyclone and air blower, with characters of low temperature, low noise and high efficiency.

7, Wood Waste Hammer Milll/Hammer Crusher has the features of reasonbale structure, firm durable, safe reliable, easy operation, and high efrficiency and are mainly used for animal feed factory,plant feeding industry, ferilizer and chemical industry, etc.

8,Wood Waste Hammer Mill/Hammer Crusher crush fertilizer waste such as animal manure, plant waste e.c.t , also can crush animal feed materials such as soybean, maize, grain e.c.t please tell us what kind of raw materials will crush and the last dimension after crushed , then we will help you choose best model.

Character:

1. unique inlet air way avoids circumfFactory Sell Small Multifunctional Wood Waste Hammer Mill/Hammer Crusherce phenomenon in the crushing process; equips "U" type hitting groove in the bottom of the crushing chamber, which enhances the output; quick-start full opening operation door, elasticity screen, easy to maintain and replace screen.

2. Uses import "NSK" bearing to guarantee the service life; The nylon stick coupling drives directly, effectively avoids bearing radiation.

3. Through dynamic balancing check, the rotor runs more stably, the noise is lower, and the performance is more ideal;

4. Through adjustment, this machine can realize coarse cracking, fine cracking, minuteness cracking, one machine multipurpose.

5. Is suitable to high quality poultry material, aquatic product material, alcohol plant, citric acid factory and so on.

Notifications when used the Wood Waste Hammer Mill/Hammer Crusher:

1 Wood Waste Hammer Mill/Hammer Crusher can be installed with different kinds of sieves, you can choose according to your actual need. If you want to process different size powder, then you need different size sieve,( sieve size:0.8cm, 1cm, 1.2cm. 1,5cm, 2.0cm)

2 Wood Waste Hammer Mill/Hammer Crusher rotor is high speed rotorying parts, hammer blades must be fixed firmly, avoid hard rawmterial entering into.

3 Hammer blades are of wear parts, should be checked time to time, when having no edges and conners, reversible or swithcing to use. But the position of hammer blades can\t be changed, or will effect balance.

4 If raw material is to big, then should be make into small one to feed in.

Speicfications of Wood Waste Hammer Mill/Hammer Crusher:

Modle

Power

(kw)

capacity

Weight|(t)

Number of hammer board

Size

(mm)

SG40

7.5

0.2-0.5

0.27

12

1310*800*1070

SG50

15

0.6-0.8

0.45

16

1380*800*1010

SG65*30

22

0.8-1.5

1.1

24

1500*1000*1100

SG65*55

37-45

1-2

1.5

48

1700*1000*1100

SG65*75

55-75

2-3

1.9

72

2100*1000*1100

SG130*100

90-110

3-4

2.3

90

2400*1000*1100

SG130*55

130-160

5-6

5.3

108

2800*1620*2100

SG130*100

160-220

7-7

6.8

160

3020*1620*2170

Picture of Wood Waste Hammer Mill/Hammer Crusher:

Spare Parts:

Alice

Skype: alice chusongtao

Phone:18353139932

Why buy from us
Chang Sheng is one of the largest manufacturer of pellet stove, pellet boiler, and pellet making machine in China. That is why we can offer you brand new products at extremely low prices.
We are the experts of biomass fuel machinery field, there is a professional team of designing and manufacturing in our factory. All the material and process are controlled strictly, that our products have a unique cost performance.

Shipping cost
Please Message or Call us. If You Have Questions About The Shipping Cost, Depending On Your Location, It May Be Cheaper!! When Contacting Us Please Provide Your Zip Code.

Packing
The kind of packing will be decided by our clients, or you can leave it to us. Whatever which one is used, all the good will be packed carefully by our professional workers to ensure the safety of your shipment.

After –sales
Quality is the soul of our factory, we have design departments, equipment installation department and after-sales department which helps our clients all over the world. They gain huge reputation for our company.
Our after-sales service includes: equipment debugging and installation,Product guidance, spare parts delivery, shipment follow up. If you have any question please contact us, We will do our best to accomplish your requirement on time.

1. Raw materials of : Potato Starch, Corn Starch , Wheat Flour, Cassava Starch etc.
2. Products made by Factory Sell Small Multifunctional Wood Waste Hammer Mill/Hammer Crusher : By changing the shaping machine, can produce , waved chips, potato chips, shrimp chips and so on. screw,shell, bulges extruded pellet chips processing line,fried snacks food machine
3. Capacity of Factory Sell Small Multifunctional Wood Waste Hammer Mill/Hammer Crusher : 80-100kg/h,250-260kg/h. screw,shell, bulges extruded pellet chips processing line,fried snacks food
4. Flow Chart of : Mixing —Extrusion —Shaping —Drying —Frying —Flavoring
5. Voltage of Factory Sell Small Multifunctional Wood Waste Hammer Mill/Hammer Crusher: Three phases: 380V/50HZ, Single phase: 220V/50HZ, we can make it according to customers' local voltage of different countries. Fried snacks food machine
6. Machines Materials of : All the machines are made by food grade stainless steel.
