Home >  Peanut Crusher Machine >  Diesel power feed crusher grinder
Diesel power feed crusher grinder Diesel power feed crusher grinder Diesel power feed crusher grinder

Diesel power feed crusher grinder

Product Description Diesel Power Feed Crusher 1. Suitable material: maize, corn stalk, grass, straw or hay. 2: Power: electricity, diesel engine, tractor PTO...
  • INFO@LDFOODMACHINE.COM | Get Latest Price
  • 850*630*800 mm
  • Within 5 working days
  • paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
  • Contact with us
  • China
  • Peanut Crusher Machine
  • CE
  • Peanut Crusher Machine

Product Description

Product Description

Diesel Power Feed Crusher

1. Suitable material: maize, corn stalk, grass, straw or hay.

2: Power: electricity, diesel engine, tractor PTO Drive

The final products are used for the cow, sheep, dog, horse and other animals eating, and the length of the grass can be adjusted.

Feed crusher with cyclone

width: 705px; height: 266px;

Diesel engine driven

Parameters

Item

Specification

Model

9FQ-36

Overall dimension:

850*630*800

Overall weight

100Kg

Rotor diameter

360mm

Matched power

5.5-7.5KW/380V

Diesel engine

10HP

Speed of main spindle

4600r/min

Hammer speed

86.7M/S

Grinding chamber width

202mm

Clearance between hammer & sieve surface

10mm

Hammer No.

12

Hammer arrangement

staggered parallel arrangement

Sieve disc width

200mm

Sieve disc cornerite

180o

Sieve pore specification

0.5mm – 5mm

Fan impeller diameter

260mm

Productivity for sieve pore diameter 2mm:

Corn: 500-650KG

Corn stalk: 80-150KG

Peanut shell: 300-500KG

Bean stalk: 130-230KGDifferent grain and crops has different productivity

Other type machines (different output) are available.

Application:

Diesel power feed grinder is a mechanical device for cutting straw or hay into small pieces before being mixed together with other forage and fed to horses and cattle.

Internal structure
Feed grinder in stock
font-size: 14px; line-height: 21px; width: 743px; height: 576px;

Diesel Power Feed Crusher working

Pictures

Diesel power feed crusher with cyclone

Main machine

width: 603px; height: 482px;

Accessories

Packaging & Shipping

Small order: Wooden case

Large order: Put in 20ft container

Company Information

Xinxiang Hengfu Electronic Machinery Co., Ltd. is professional supplier with the ability to manufacture and supply each and every machine in the feed production line. With an intricate knowledge of each key process, we can supply a compatible solution from raw material intake to finished feed bulk loading.

We supply turnkey solutions of feed production, from evaluation, design, project management, process engineering to procurement manufacturing, installation, commissioning. We study every details of the pelleting solution, so that to ensure you get the best feed equipment, best service and best plan.

Further information, click here

Flowchart for 0.5-2 t/h small pellet feed mill

FAQ

How to select suitable animal feed grinder?

Pls inform us what material need crush and required capacity.

1. Raw materials of : Potato Starch, Corn Starch , Wheat Flour, Cassava Starch etc.
2. Products made by Diesel power feed crusher grinder : By changing the shaping machine, can produce , waved chips, potato chips, shrimp chips and so on. screw,shell, bulges extruded pellet chips processing line,fried snacks food machine
3. Capacity of Diesel power feed crusher grinder : 80-100kg/h,250-260kg/h. screw,shell, bulges extruded pellet chips processing line,fried snacks food
4. Flow Chart of : Mixing —Extrusion —Shaping —Drying —Frying —Flavoring
5. Voltage of Diesel power feed crusher grinder: Three phases: 380V/50HZ, Single phase: 220V/50HZ, we can make it according to customers' local voltage of different countries. Fried snacks food machine
6. Machines Materials of : All the machines are made by food grade stainless steel.
