Home >  Peanut Crusher Machine >  high quality water drop hammer mill for grinding maize for poutlry feed production line
high quality water drop hammer mill for grinding maize for poutlry feed production line high quality water drop hammer mill for grinding maize for poutlry feed production line high quality water drop hammer mill for grinding maize for poutlry feed production line

high quality water drop hammer mill for grinding maize for poutlry feed production line

can automatically finish raw materials preparation, extrusion, shaping, cutting, drying and flavoring at a time.high quality water drop hammer mill for grinding maize for...
  • INFO@LDFOODMACHINE.COM | Get Latest Price
  • 2100*970*1050mm
  • Within 5 working days
  • paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
  • Contact with us
  • China
  • Peanut Crusher Machine
  • ISO9001:2008/CE
  • Peanut Crusher Machine

Product Description

can automatically finish raw materials preparation, extrusion, shaping, cutting, drying and flavoring at a time.high quality water drop hammer mill for grinding maize for poutlry feed production line has the advantages of more machines choice, flexible and diverse configurations, wide range of raw materials application, numerous in products variety and easy opration. high quality water drop hammer mill for grinding maize for poutlry feed production line can make the puffed snacks, corn bars, corn sticks and so on. After being puffed by , the products are crispy, easy to digest and unique taste. They are the perfect leisure food for high quality water drop hammer mill for grinding maize for poutlry feed production line consumers.

of high quality water drop hammer mill for grinding maize for poutlry feed production line comprises of U-shape barrel,transmisstion parts and ribbon agitating blades usually have doubleor triple layers with outside screw gathering material from side to center and inside screw transmitting the material from center of high quality water drop hammer mill for grinding maize for poutlry feed production line to sides to form convection mix.high quality water drop hammer mill for grinding maize for poutlry feed production line has a very good effect for mixing spice or dry powder with liquid.

comes from defatted soy flour, which is a by-product of soybean oil, so it is plentiful in supply. high quality water drop hammer mill for grinding maize for poutlry feed production line is also quick to cook and a great source of vegetable protein without all the fat.high quality water drop hammer mill for grinding maize for poutlry feed production line uses the newest production equipments. are researched and developed according to the market demand and basing on the advanced equipments. Jinan Joysun Machinery Co., Ltd. high quality water drop hammer mill for grinding maize for poutlry feed production line has become the serialization and many kinds of collocations can meet the different customer's needs.

Product Description

Product Application

Grinding or particle-size reduction is a major function of feed manufacturing. Many feed mills pass all incoming

ingredients through a feed hammermill, electric chicken feed grinder for sale, corn grinder for chicken feed,

feed crusher ,chicken feed hammer mill machine for several reasons:
(a) clumps and large fragments are reduced in size,
(b) some moisture is removed due to aeration,
and(c) additives such as antioxidants may be blended.
The grinding of ingredients generally improves feed digestibility, acceptability, mixing properties,pelletability, and

increases the bulk density of some ingredients. It is accomplished by mechanical operations involving impact,

attrition. Therefore,hammer mill is the best choice for the feed manufacturing.

Technical data for chicken feed hammer mill

Motor

Power Kw 55
Rotation speed rpm/min 2978
Type &brand asynchronous china or high quality water drop hammer mill for grinding maize for poutlry feed production line



Main data
Capacity T/H 5-8
Hammers Qty Pcs 70
Rotor diameter mm 600
Crushing chamber mm 600
Screen hole mm 2-8

Equipped with
cyclone mm 1000
fan Kw 11
Airlock Kw 2.2
width: 750px; height: 750px; margin-left: 0px; margin-top: 0px; width: 750px; height: 750px; margin-left: 0px; margin-top: 0px;

Main Features

1.Universal type product, stable performance, easy for installation, operation and maintenance.
2.Coupling direct drive is adopted, generating high transmission efficiency and accurate drive ratio.
3.Built-in grinding rotors and efficient grinding without dead corner.
4.Portable operation door with convenience, strength-saving and high security.
5.A variety of sieve sizes are available to choose and the wrap angle of the sieve is large up to 300°
6.Scientific and reasonable hammer arrangement and reasonable gap between hammer and the screen,
ensure uniform fineness of finished products, little vibration and high productivity.
7.There are two groups of pin holes on the rotor disc, uniformly distributed on two concentric circles of
different diameters, by which coarse and fine grinding can be achieved.
width: 750px; height: 563.088px; margin-left: 0px; margin-top: 0px; width: 300.6px; height: 323.1px; margin-left: 0px; margin-top: -3px; width: 370.8px; height: 233.1px; margin-left: 0px; margin-top: 0px;

Working principle
Animal feed hammre mill, corn feed grinder are mostly impact grinders with swinging or stationary steel bars

forcing ingredients against a circular screen or solid serrated section designated as a striking plate.

Material is held in the grinding chamber until it is reduced to the size of the openings in the screen.

The number of hammers on a rotating shaft, their size,arrangement, sharpness, the speed of rotation, wear

patterns, and clearance at the tip relative to the screen or striking plate are important variables in grinding

capacity and the appearance of the product. Heat imparted to the material, due to the work of grinding, is

related to the time it is held within the chamber and the air flow characteristics.

Impact grinding is most efficient with dry, low-fat ingredients, although many other materials may be reduced

in size by proper screen selection and regulated intake.
Associated with grinding feeds, a sieving system is required which classifies materials to any desired particle
size. The "overs" in this system may be re-ground or rejected. The "throughs" may be selected to comply with
livestock and poultry requests for size and mixed according to formula specifications. Feeds sifted through
3-8mm opening have been successfully used for increasing survival and growth of livestock and poultry.
Hammermill or impact grinding of dry feeds, especially cereal grains, creates particles within the range
called "dust", and a dust-collecting system may be necessary to remove this. An excess of dust in the feed
may lead to gill disease, a situation where organic matter adhering to gills becomes a nutrient for bacteria
or parasites.

width: 750px; height: 750px; margin-left: 0px; margin-top: 0px;Certificationswidth: 181.5px; height: 253.551px; margin-left: 0px; margin-top: -17px; width: 181.5px; height: 248.368px; margin-left: 0px; margin-top: -11px; width: 181.5px; height: 257.125px; margin-left: 0px; margin-top: -42px; width: 181.5px; height: 263.043px; margin-left: 0px; margin-top: 0px;Detailed Imageswidth: 390.764px; height: 220px; margin-left: -6px; margin-top: 0px;

Guide Plate

A chicken feed grinder has two feeding directions.The guide plate can control feeding into crushing chamber from left or right side.The air cylinder of electric reversing valve controlsthe guide plate to change direction and the travel switch alters the motor rotating directionconforming to the feeding direction.

Baffle

At the moment the raw material begin to flow into inlet,

their powerful impact force can damage the inner wall

of the feed hammer mill, so the baffle can protect and

surge, the corrugated design can make the service

lifetime long.

width: 390.764px; height: 220px; margin-left: -7px; margin-top: 0px; width: 390.764px; height: 220px; margin-left: 0px; margin-top: 0px;

Motor

A feed crusher always chooses a powerful asynchronous type motor as a power. If you need, the high quality water drop hammer mill for grinding maize for poutlry feed production line can be available.The motor connects the rotor shaft by couplingto drive the rotor rotating in the crushing chamber.Its service lifetime can be up to 10 years with about 2900 rmp/min, so the capacity is guaranteed.


Maintenance hole

When you need to change the worn hammers, do not

need to take apart the whole feed grinder, you only

gradually pull the hammer shaft out of the maintenance

hole to take off the hammers, then push forward to

arrange the new hammers.

It is very convenient and easy operation.

width: 196.2px; height: 278.1px; margin-left: 0px; margin-top: -10px;

Hammer&screen

A rotor consists of axis,lockpin,hammer carrier plate and hammers.

The bear can support the rotor in the crushing chamber.

The hammers are arranged with symmetric alternating

regulation to avoid hammer mill vibration.

There are two screens which is suitable for 2-8 mm feed

size for poultry/animal/livestock.

width: 367.4px; height: 275px; margin-left: 0px; margin-top: 0px; width: 750px; height: 750px; margin-left: 0px; margin-top: 0px; Maize grinding hammer mill is used to crush the corn,soybean, sorghum,wheat into particles or power in theanimal/poultry feed production line for feed mill. There is a impurity removal device before crushing to aviod to damage the hammer mill, a set of dust collecting system to avoid air pollution in the workshop.Then the particles or power can flow into next processing.

Soybean grinding macine are always applied with feed mixer as a feed mash making group for chicke layer or pig.

width: 750px; height: 750px; margin-left: 0px; margin-top: 0px;Our Servicewidth: 331.1px; height: 330px; margin-left: 0px; margin-top: 0px; width: 331.1px; height: 316.8px; margin-left: 0px; margin-top: 0px;

Pre-sale service

* Inquiry and consulting support.
* supply solution
* View our Factory.

After-sale service

* Training how to instal the machine, training how to

use the machine.
* Engineers available to service machinery overseas.

Packing & Deliverywidth: 400px; height: 320px; margin-left: -12px; margin-top: 0px;
Packaging
Size 1800 (L) * 950 (W) * 1300 (D)mm
Weight 0.85T



Packaging Details

The normal package is wooden box. If export to european countries,the
wooden box will be fumigated.
If container is too tigher,we will use
PE
film for packing or pack it
according to customers special request.
Related Productswidth: 180px; height: 180px; margin-left: 0px; margin-top: 0px; width: 180px; height: 180px; margin-left: 0px; margin-top: 0px; width: 180px; height: 180px; margin-left: 0px; margin-top: 0px; width: 180px; height: 180px; margin-left: 0px; margin-top: 0px;Our Companywidth: 750px; height: 732px; margin-left: 0px; margin-top: 0px;

Shandong Double Crane Machinery Manufacture Co.,Ltd. is located in economical and technological
development zone, Leling city,Shandong province,very close to the expressway from Beijing to Shanghai.
Our company is the high and new technological enterprise dedicated to manufacture feed pellet machines and
biomass pellet machines to worldwide users.
Sticking to the product developing ideas of simplicity,perfection,quality and innovation,we have been always

high quality water drop hammer mill for grinding maize for poutlry feed production lineed on designing and manufacturing feed pellet machines and biomass pellet machines since the foundation

in 2005.
We had cooperated with domestic famous universities like Shandong University,Jinan University and Shandong
Agricultural University in feed pellet production line and biomass pellet production line research and development
since 2008.We had obtained more than 30 patents and successfully developed 8 series of products,including 60
different kinds of machines.
In the feed pellet industry ,we had achieved advanced level in man-machine design,functional design,automatic
control and user experience and became the professional pelle
t mill manufacturer in China.We have strong
competitive advantages in feed production line with the capacity of 1-30 tph and biomass pellet complete line
with capacity of 1-50tph.Until now,we had installed more than 1200 sets of machines worldwide.
In recent years,our company continuously increase investment.We had invested up to 60 million Yuan to build
19,200 square meters manufacturing base and 10 million Yuan for technological innovation,in-depth automatic
and integrative technology development.These investments have greatly promoted the upgrading of the machines,
offering best quality solutions for feed industry and biomass pellet industry.Double Crane Machinery is willing to
become your partner with our high price-performance products,excellent quality and perfect after-sales service.


Promise provide customer Best Quality! Best Price! Best Service!
