Home >  Pellet feed production line >  Made in China animal feed pellet making line with capacity of 10T/Day
Made in China animal feed pellet making line with capacity of 10T/Day Made in China animal feed pellet making line with capacity of 10T/Day Made in China animal feed pellet making line with capacity of 10T/Day

Made in China animal feed pellet making line with capacity of 10T/Day

Product Description Animal feed pellet production line(2T/H) Introduction: The animal feed pellets can be made from any type of...
  • INFO@LDFOODMACHINE.COM | Get Latest Price
  • Within 5 working days
  • paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
  • Contact with us
  • China
  • Pellet feed production line
  • ce
  • Pellet feed production line

Product Description

Product Description

Animal feed pellet production line(2T/H)

Introduction:


The animal feed pellets can be made from any type of corn, grains and all type of agriculture stuff.

The finished pellets diameter can be 3mm, 4mm, 5mm, 6mm, 8mm according to client needs.

Flow Chart:

Machine list:

Machine list of 2t/h chicken feedstuff pellet production line
NO. Name Qty(set) Remark
Raw material receiving and grinding system
101 Raw material pit and grizzly 2
102 Blower 1 operation smooth, low noise
103 Pulsed dust collector 1

New high effective dust removing , frame

detachable, bag structure

104 Air lock 1 Bearing never feed material
105 Bucket conveyor 1

High strength plastic bucket, bottom strap wheel

is screen, no adhere raw material

106 Cylinder screen remove raw material rope head, stone, clod
107 Silo 1
108 Blower 1 operation smooth, low noise
109 Pulsed dust collector 1

New high effective dust removing , frame detachable,

bag structure

110 Settling chamber 1
111 Screw conveyor 1 special design , reliable and longlasting
112 Vane wheel FM Iron-removing feeder 1 transducer control feeder, discharging material evenly
113 Water dripping hammer mill 1

whole open operating door, easy to change sieves, can

realize big and small size grinding

114 Bucket conveyor 1

High strength plastic bucket, bottom strap wheel is screen,

no adhere raw material

Mixing system
201 mxing silo 1
202 Pneumatic valve 1

flexible , no leak material,pneumatic element adopt Yadeke

In Taiwan

203 single shaft doubel strap mixer 1

sube section is circular, rotor can be takeout from one side,

easy for maintance, mixing evenly, mxing time is not extend

5 minutes, without leaking material

204 Manual Three-way 1 reducer driven
205 bucket conveyor 1

High strength plastic bucket, bottom strap wheel is screen,

no adhere raw material

206 magnectic 1 high strength magnet, iron removing up to 99.9%
pellet making system
301 pellet making silo 1
302 pellet machine 1

High quality circle die. Stainless steel conditioner, operation

balance, widely used in aquatic feed and livestock feed

303 Air lock 1
304 counterflow pellet cooler 1

counterflow cooler, cooling evenly, with broken, time can be

adjusted, without residue

305 blower 1
306 cyclone discharger 1
307 Air lock 1
308-1 pellet cutting machine 1

Cutting the big pellets into small pellet which is proper for

chicken and other animal, no broken

309-2 Screening 1
309 Bucket conveyor 1
310 pellet packing machine 1 weighting automatically, with sealing and conveyor
Accessory system
501 Air compressing system 1
Air compressing pipe system 1
502 steam supply system 1
Electrical control system 1

More pictures:

Packaging & Shipping

Packaging: Wooden Crate or Pallet or bare package in standard containers for export;

Shipping: All machines will be sent by sea, if you need other kind of transportation, please inform us in advance. And all machines would be shipped in 7 days after the receipt of payment. Before and after shipping, we will take photos of machines and send photos to client.

Our Services

Quality guarantee terms: Quality guarantee is one year. Spare parts we supply at factory cost lifetime.

We will be responsible for any broken which are caused by machine-self and quality problem, other situations which are caused by wrong operation, man-made problems etc will be in buyer’s response, and we will help to solve by video ASAP. If big problem we will send engineer to working site within one week.

Contact Us

Anything remaining unclear, please feel free to contact.


Contact name: Jessie Han
Phone/WhatsApp/Made in China animal feed pellet making line with capacity of 10T/Day +86 131 3714 6315
Skype: amanda892012

As a leader in the food machinery industry ,we adhere to the principle of honest and trustworthiness all the time,and have a good reputation on the international market.Over the years, we explore and research in extrusion technology, so that the screw extrusion technology application areas are more extensive. Our single and double screw device has been used in the production of snack foods, breakfast cereals: corn chips, fried food, bread crumbs, soybean tissue protein, pet food, over 20 different functions and yield of the production line for choice; also can manufacture special designed according to special requirements the user's.Our products sell well both at home and abroad.Such as Gemany,Italy,Holland,Spain,Russia,Canada,USA,Mexico,Columbia,Japan,SouthKorea,Uzbekistan,Egypt,South Africa and so on.Welcome your enquiry.

3333333 professional production 111111.11111111 is a continuous feeding operation. 22222 production can be used for cattle feed processing, sheep feed processing, horse feed processing, rabbit feed processing, poultry and poultry feed processing, is a new type of small household particle machine, can also be used as feed processing plant Special particle machine, no dust, add the mixed powder feed into the hopper when working, no heating, no water, no drying, once formed by extrusion, the surface of the processed particles is smooth, the hardness is moderate, and the internal curing is deep and transparent. Starch gelatinization, protein coagulation and degeneration, improved nutritional value and digestion and absorption capacity,
