Dog food machine/ Dog food production line/ Dog food processing lineProduct Description
Presentation of the dog food processing line
Flow chart of the dog food processing line
There are 7 processes as showed in the flow chart:
1. Crushing. 2. Mixing. 3. Extruding. 4. Drying. 5. Cooling. 6. Seasoning. 7. Packing
Brief introduction of main machines
1. Crushing process------Crusher machine/ Hammer mill
|It's a common hammer mill with simple structure, and used for crushing different material, such as corn, wheat, fish meal, soybean meal and so on. Generally, the sieve hole of crusher is 0.8mm for fish feed material. So the fineness of crushed material can reach the requested mesh.|
2. Mixing process------Mixer machine
|Mixer machine has one single shaft inside, which is mainly used to mix all kinds of powder, such as the wheat flour , corn flour , sorghum flour and so on. It also could mix other micro- ingredients such as vitamins, amino acids, trace elements and other feed additives, which is the key steps on the feed production line. With fast mixing time 10-15 minutes, the capacity can reach 100kg per batch.|
3. Extruding process------Feed extruder machine/ Feed making machine
The feed extruder machine is the most important equipment in the feed pellet line. It is widely used for processing grain materials into floating and sinking fish feed, different shaped pet food, poultry feed pellets and so on. The floating feed can float on the water for at least 12 hours without water pollution. The feed diameter can be 1-20mm.
4. Drying process------Feed dryer
The dryer belongs belt type hot air dryer machine, which is mainly used in the feed processing. This dryer could reduce the moisture of pellet quickly due to its multilayer belt circle round design.
5. Cooling process------Cooler machine
The counterflow cooler principle is adopted to cool the pellets with high temperature and moisture. Hot air touches hot pellets and cool air touches cool pellets so as to avoid the pellet surface crack caused by sudden cooling produced by direct touching between cool air and hot pellets. At the same time, the airlock is used for feeding and space of air inlet bigger, therefore it can get better cooling effects.
6. Seasoning process------Coating machine/ Seasoning machine/ Flavoring machine
|The coating machine is modified from ribbon mixer. So the working principle is similar to the mixer. After put the feed and flavorings inside, the machine can mix them by the stirring shaft. The shaft speed is very slow, so it cannot break the feed. The oil pump is connected to inner spraying nozzle by pipes and oil tank, which can spray oil on the surface of pellet feed.|
7. Packing process------Packing machine
|The complete set of packing machine includes weighing scale, belt conveyor, sealer and control cabinet. The packing machine can be used to pack animal feed pellet, sugar, rice, wheat, grill,etc. It has advantages of wide quantitative extent, high precision and a platform that can be raised and lowered, making it have more functions and higher efficiency. It can pack feed into plastic bags with 1-50kg per bag, with packing error 0.1%F.S.|
The following are parameters of all dry models of feed extruder machine, please kindly check this according to capacity requirement.
|Model||Capacity(t/h)||Motor power(kw)||Feed power(kw)||Screw Dia(mm)||Cutting power(kw)|
Final feed pellets sample made by the dog food processing line
Packaging & Shipping
1. These machines will be packaged by plastic film, and wooden case to ensure a safe delivery.
2. If the machines are shipped by full container, then they can be loaded into container directly.
ZHENGZHOU FANWAY MACHINERY MANUFACTURING CO.,LTD is the professional manufacturer which has devoted in developing, designing and manufacturing top quality pellet making equipment. Engineers research and experiment pellet mill and pellet plant design; skilled labor assembly machines: pellet mill, pet & fish feed extruder, hammer mill, mixer, dryer, cooler, packaging machine, etc.
Furthermore our experienced and professional pellet plant project consultants can offer you turnkey wood pellet plant solution, animal feed pellet plant solution, fish feed pellet plant solution as well as pellets production solution.
Jinan Joysun Machinery Co., Ltd. is a high-tech enterprise integrating science, industry and trade. It is committed to the development of Dog food machine/ Dog food production line/ Dog food processing line expanded snack food equipment, tissue protein equipment, pasta/macaroni equipment, corn flakes production line, pet food equipment and experimental extruders, etc. Development, production and sales.
Dog food machine/ Dog food production line/ Dog food processing line's screw has a taper, so there are unequal gaps between the sleeve and the material. When the screw rotates, the material will be pushed forward, resulting in shear deformation and internal friction, so that the mechanical energy becomes thermal energy and variable performance. Dog food machine/ Dog food production line/ Dog food processing line can produce a variety of pasta products, now can produce rice flour, hollow powder and other product technology has matured.
