Product Description

Product Descriptionwidth: 300.6px; height: 214.2px; margin-left: 0px; margin-top: -7px;

width: 300.6px; height: 300.6px; margin-left: 0px; margin-top: 0px;

Our Factory

Our factory occupa 30000 square meters. among of 10000 square meters modernization workshop, 4000 square meters for office . the rest are for workers dormitory and for garden.

Finished Machines In Factory

this is our finished machines show room , our processing workshop and finished product workshop are by separately .

15T/H Cattle Sheep Chicken Food Pellet Production Machinery Line Description :


1.This line widely applied product with mature technology .
2.The main driving adopts high-precision gear drive, so that the output is improved by about 20% when compared with that of belt drive.
3.Imported high-quality bearing and oil seal are adopted to ensure efficient, stable and low-noise whole machine operation . the granulating room is equipped with air suction temperature reducing system .
4.The feeder adopts variable-frequency and variable-speed motor to ensure the quality of discharged particles .
5.Ring dies with multiple kinds of bore diameters are optional . and high-quality craft ring dies are adopted, so that the service life is long. The discharged particles are smooth and the quality is high .
6.International advanced compensation type snakelike spring coupling has the propertied of novel and compact structure, high safety, low noise and low fault rate.
7.Plus-size conditioner and jacket type conditioner are selectable to strength the particle conditioning effect.


Product technical parameters :

SZLH32 SZLH35 SZLH40 SZLH42 SZLH508 SZLH558
SZLH678 SZLH768
1 Capacity 2-5T/H 2-8T/H 2-10T/H 3-12T/H 4-20T/H 6-22T/H 10-30T/H 12-35T/H
2 Main power 37kw 55kw 75/90kw 110kw 132/160kw 160/180/200kw 220/250kw 280/315kw
3 Power of feeder 0.55kw 1.5kw 1.5kw 1.5kw 1.5kw 2.2kw 2.2kw 2.2kw
4 Power of conditioner 2.2kw 3kw 3kw 5.5kw 7.5kw 7.5kw 11kw 15kw
5 Inner diameter of die 320mm 350mm 400mm 420mm 508mm 558mm 678mm 768mm
6 Die speed 305RPM 336RPM 307RPM 287RPM 287RPM 287RPM 287RPM 287RPM
7 Feeder speed 12-120RPM
8 Conditioner speed 350RPM
9 Pellets size Diameter 2,3,4,4.5,5,6,8,10mm
10 Rollers number 2 pcs
Detailed Imageswidth: 750px; height: 750px; margin-left: 0px; margin-top: 0px; width: 750px; height: 967.742px; margin-left: 0px; margin-top: 0px;Packing & Deliverywidth: 750px; height: 499.5px; margin-left: 0px; margin-top: 0px; width: 750px; height: 446.25px; margin-left: 0px; margin-top: 0px;

15T/H Cattle Sheep Chicken Food Pellet Production Machinery Line packing

Successfull Casewidth: 371px; height: 246.715px; margin-left: 0px; margin-top: -28px; width: 371px; height: 247.457px; margin-left: 0px; margin-top: -36px;

15T/H Cattle Sheep Chicken Food Pellet Production Machinery Line in china

Poultry Feed Making Line In Bangladesh

width: 371px; height: 278.621px; margin-left: 0px; margin-top: -36px; width: 371px; height: 370.206px; margin-left: 0px; margin-top: -159px;

15T/H Cattle Sheep Chicken Food Pellet Production Machinery Line in Austrilian

Chicken Feed Making Machine Manufacture

Contact Information

To Know More 15T/H Cattle Sheep Chicken Food Pellet Production Machinery Line , pls contact with us freely.


contact person: Mrs Winni

E-mail: info(at)15T/H Cattle Sheep Chicken Food Pellet Production Machinery Linemachinery.com

Cell/15T/H Cattle Sheep Chicken Food Pellet Production Machinery Line: 0086 15T/H Cattle Sheep Chicken Food Pellet Production Machinery Line

Skype: winni.duan

15T/H Cattle Sheep Chicken Food Pellet Production Machinery Line is suitable for foods such as casual products, soy products, meat, and aquatic products. is widely used in large, medium and small-sized fried food manufacturers, school canteens, and large-scale restaurants.
Jinan Joysun Machinery Co., Ltd. is a modern food machinery and equipment manufacturing enterprise integrating R&D, manufacturing, sales, and after-sales services.
The main production of food frying equipment, cleaning equipment, blanching cooking equipment, pasteurization line, drying machine, vacuum packaging machines and other food processing equipment.
15T/H Cattle Sheep Chicken Food Pellet Production Machinery Line is the essence of absorbing the same kind of equipment, retaining the advantages of large-scale equipment for enrichment, and referencing the user's feedback information throughout the country for design and development.
has the characteristics of low one-time investment, low energy consumption, multiple functions, small size, high profit, convenient use and maintenance. The full set of equipment consists of peeling, slicing (strips), fluttering, dehydration, oil-water mixed frying, degreasing, seasoning, packaging and auxiliary equipment.
