animal feed pellet machine manufacturer in China

animal feed pellet machine manufacturer in China

Professional High quality sinking and floating animal feed pellet machine manufacturer in China Description of sinking and floating animal...
  • Negotiation | Get Latest Price
  • 1460*1140*840mm
  • Within 5 working days
  • paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
  • 34
  • Original animal feed pellet machine manufacturer in China
  • YufChina
  • ISO/CE
  • DGP60-C

Product Description

Professional High quality sinking and floating animal feed pellet machine manufacturer in China

Description of sinking and floating animal feed pellet machine manufacturer in China

animal feed pellet machine manufacturer in China is widely used for producing grains into high-grade aquatic feed pellets for fish, catfish, shrimps, crab etc. The puffing pellets can float on water surface for over 12 hours,.According to your capacity and material ,We wil suggest you different model fish feed pellet machine.

Working principle of animal feed pellet machine manufacturer in China

Feed material by feeding device, it will be pressed by the screw shaft under high pressure and temperature which makes the raw material fully puffed . Pellets can be different shape and size by changing the mold . Then cutting blades will cut the pellets into different length .

Features of sinking and floating animal feed pellet machine manufacturer in China

1.Main parts adopt special alloy steel,dealed by heat treatment,long life time than usually machine.

2.Mold can be change easily ,can met different fish,shrimp,etc.

3.Without any adhesive.Floating fish feed can keep floating for more than 12hours without resolve, The floating time can be controlled by the puffing degree adjustment.

4.Adopt electric heating system improve feed expansion rate and delay the pellets floating time.

5.High temperature puffed process can kill the salmonellosis and bacterial infections,mean while make pellets easily digested.

6.Different of dry type and wet type floating fish feed pellet machine :

Wet fish feed pellet machine need boiler to supply steam,dry type don’t need boiler.

Dry type more cheaper than Wet type .

Wet type can produce much smooth and better quality feed pellet .

Specification of Dry type animal feed pellet machine manufacturer in China

Model

Capacity

(kg/h)

Power

(kw)

Screw diameter

(mm)

Cutting power

(kw)

DGP60-C

120-150

15

φ60

0.4

DGP70-B

180-200

18.5

φ70

0.4

DGP80-B

200-250

22

φ80

0.6

DGP90-B

300-350

37

φ90

0.8

DGP120-B

500-600

55

φ120

2.2

DGP135-B

700-800

75

φ133

2.2

DGP160-B

1000-1200

90

φ155

3.0

DGP200-B

1800-2000

132

φ195

3.0-4.0

Dry type of animal feed pellet machine manufacturer in China

Wet type of animal feed pellet machine manufacturer in China

Model

Capacity

(kg/h)

Power

(kw)

Feed power (kw)

Screw diameter

(mm)

Cutting power

(kw)

Conditioning power(kw)

DSP60-B

180-200

15

0.4

Φ60

0.4

0.75

DSP70-B

250-300

18.5

0.6

Φ70

0.6

0.75

DSP80-B

350-400

22

1.1

Φ80

0.8

1.1-1.5

DSP90-B

500-600

37

1.1

Φ90

1.1

2.2

DSP120-B

700-800

55

1.1

Φ120

1.5

2.2-3.0

DSP135-B

1000-1200

75

1.5

Φ135

2.2

3.0-4.0

DSP160-B

1800-2000

90

2.2

Φ155

2.2-3.0

4.0-5.5

DSP200-B

3000-4000

132

2.2

Φ195

3.0-4.0

5.5

Photos of animal feed pellet machine manufacturer in China

DSP60-B

DSP70-B,80-B,90-B,120-B-135-B,160-B

Finished animal feed pellet machine manufacturer in China

Contact information about our animal feed pellet machine manufacturer in China

ZHENGZHOU YUFENG HEAVY MACHINERY CO., LTD

WHATSAPP 0086-13526817088
Add: Gongye Road, Shangjie District, Zhengzhou City, China



....
