Floating fish feed pellet drying machine / fish food pellet drying machine / floating fish feed pellet dryer Floating fish feed pellet drying machine / fish food pellet drying machine / floating fish feed pellet dryer Floating fish feed pellet drying machine / fish food pellet drying machine / floating fish feed pellet dryer

Floating fish feed pellet drying machine / fish food pellet drying machine / floating fish feed pellet dryer

have wide range of equipment sizes to suit your Floating fish feed pellet drying machine / fish food pellet drying machine / floating fish feed pellet dryer space and its lab...
  • INFO@LDFOODMACHINE.COM | Get Latest Price
  • 8800*5800*4500mm
  • Check with us
  • paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
  • Contact with us
  • China
  • Fish Feed Pellets machine
  • Fish Feed Pellets machine

Product Description

have wide range of equipment sizes to suit your Floating fish feed pellet drying machine / fish food pellet drying machine / floating fish feed pellet dryer space and its lab item sterilization and decontamination needs of BB.Find here manufacturers, suppliers & exporters in China,Get contact details & address of companies manufacturing and supplying Floating fish feed pellet drying machine / fish food pellet drying machine / floating fish feed pellet dryer. services and products used in hospitals, laboratories, scientific institutes and pharmaceutical industry.

, Wholesale Various High Quality Floating fish feed pellet drying machine / fish food pellet drying machine / floating fish feed pellet dryer Products from Global Peanut Shelling Machine Suppliers and Factory,Importer,Exporter.This small Floating fish feed pellet drying machine / fish food pellet drying machine / floating fish feed pellet dryer mainly contains 3 parts, the destoner for peanuts, conveyer and the groundnut sheller. Floating fish feed pellet drying machine / fish food pellet drying machine / floating fish feed pellet dryer features compact structure, stable operation and less noise. One of the advantages of is that the conveyor part is effective and economical.

Find here Floating fish feed pellet drying machine / fish food pellet drying machine / floating fish feed pellet dryer manufacturers, suppliers & exporters in China. Get contact details & address of manufacturing and supplying Floating fish feed pellet drying machine / fish food pellet drying machine / floating fish feed pellet dryer, , Pellet Frying Line across Shandong,China.
Features: adopts flour, corn starch and potato starch as raw material, makes food through the process of extruding, cooking, shaping, drying and frying.By choosing different dies, you can make different shapes food such as shell, screw, square tube, round tube, lotus root slices etc.

Product Description

Floating fish feed pellet drying machine / fish food pellet drying machine / floating fish feed pellet dryer

The extruded products have high moisture content at die exit. These are taken away by downstream conveying system to dryer for drying. A feed spreader located at dryer inlet distributes the extruded product evenly across the whole dryer width for even drying and moisture content.

The air used in drying is first heated up in the heat exchanger area, then circulating around and thru the dryer screen, removed heat and moisture at the same time. A small portion of wet air is exhausted and replaced by fresh cold air bring in that is being heated up by the heat exchangers. Majority of these dry hot air is then recycled, so as to reduce energy consumption.

The dried extrudates at dryer exit are then transferred to cooler for cooling.

Dryer system characteristics:

· Capacity: Up to 16 TPH

· Module Designs

· Even product distribution

· Adjustable retention time

· Recycled air chamber

· Controlled balanced airflow for Uniform drying

· PID controlled steam system for low steam consumption

· PLC Control for easy start-up and efficiency

Technical specifications for ANTEXT Dryer

Extruded Product Moisture

@ Dryer Inlet: 25%

@ Dryer Outlet: ±13%

Steam Consumption: S 180 kg/ton/hr

Temperature Range: 80 - 120C

Compressed Alr: 400L/h (0.6-0.8Mpa)

Model

ANTEXT

D13

D47

D811

D1116

Capacity

TPH

1-3

4-7

8-11

11-16

Connected Power

kw

46.8

93.05

137

182.45

Steam Required

kg/h

900-1150

1800-2300

2300-3000

3000-3700

Our Advantages:

· Floor between passes to separate air flows.

· Dryer is divided into two temperature and airflow zones.

Available in many designs and sections

Single or double decks

Separate dryer and cooler or

Dryer + cooler 2 in 1 design

Modular design, easy to increase capacity by adding sections

Fixture welded frame for truer fit at installation.

Heavy duty frame and components

Stainless steel material in high-corrosion areas e.g side panels above fine return screw

Completely assembled and tested in factory

±80% re-cycled air for dryer energy saving

Feed Spreader:

Oscillating spout spreader to spread product across width of conveyor.

Spout is stainless steel construction.

Welded tubular frame.

Driven by 0.55 kW (0.75Hp) motor with variable frequency drive.

On-line stroke adjustment and on-line dwell adjustment.

Dryer Screen:

Wire mesh screen:

more opening area for proper even drying

Polyester screen standard:

stainless screen as option

Width: 3m wide, Length: 8 ~ 23m Length

Balanced Airflow for Uniform Drying.

Heated airflow from either side of dryer.

Minimizes uneven drying across bed.

Eliminates need for air diverters.

Heated airflow up or down through product.

Reduces uneven drying through bed.

Process Flexibility For Future Operations.

Airflow direction quickly changed.

Accommodates product changes.

Adapts to process modifications.

For proper equipment sizing, ANTEXT will require following inputs from Buyer

Monthly production tons/month:

No of working hours per day

List major final product sizes and their percentages

Final product density range kg/m3

Product Moisture content required:

Formulation:

Starch

Protein

Fat

Fiber

Ash content
