1). Animal pet food production line dog food production line china fish feed making machine uses meat meal, fish meal, corn powder, soya meal and other grains powder as main materials to make the pet food, such as dog, cat, fish, bird food etc. With different shapes and tastes by changing the dies and formulations. It adopted Modular Circular Groove Screws and by changing the screw assembling sequence,slenderness ratios different products can be made such as corn flakes, puffing snacks, protein etc.
2. Raw Materials: adopts corn flour, fish meal as raw materials
3. Products: different shapes are made by adjusting the dies from extruder
4. Capacity: 150kg/h, 240kg/h, 500kg/h, 1ton---3ton/h
5. Flow chart:
Mixing system---Extrusion system---Drying system---Flavoring system---Packing system
6. Voltage in China: Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers’ Local voltage according to different countries
7. Machines Materials: All the machines are made by stainless steel, this line is with reasonable design and with high automation; the screws are made by alloy steel, with building block system structure and self-cleaning function
8.Specification of fIsh feed machine floating fish feed pellet machine:
Jinan Saibainuo Machinery Co., Ltd for food machine manufacturering in China since 2004, offer competitive advantage machines, so with us your money in safe, your business in safe.
Our high capacity production line in our factory.
Our customer come to our factory to inspect the machines.
The inside structure of our twin screw extruder.
Our multi-layer dryer.Detailed Images
Motor Power: 3KW
Throughput: 20kg per loading (5-6 minutes per loading)
Mix powder raw material with water
1. stainless steel material(1.5mm).
2. new handle-opened design of discharge holes,no material leak
3.High speed can mix material better than other slow mixer.
Motor Power: 1.1KW
Screw speed: 300rpm
convey height range:1.5~2.5M
barrel diameter: Φ141mm
powder material can be conveyed in the stainless steel roller to the feed machine of extruder without leaking, dust and pollution; feed quantity is even and stable.
stainless steel material
Total power: 37kw
Main Motor Power:22KW
Cutting motor: 1.5kw
Extruder diameter:Φ65 mm
Extrude and cook raw material into different size and shapes
Screw material is 38CrMoAl with nitriding treatment, the hardness is
60HRC.. The barrel also use good material, hardness is 55HRC.
The gear box has forced lubrication system.
All motors can be adjusted the speed by Inverter.
The Extruder can change different moulds to produce different Shapes product.
Heating powder: 27kw
There are Three layers inside,each layer is 5 meters long, it can save space and energy. Electricity heating,used to bake and dry food.
The net belt running speed can be controlled by Inverter, to change the food drying time in the dryer.
Heating adopts the electric heat tube.
It has automatic temperature Control system.
The belt and the cover are all stainless steel
Motor Power: 1.5KW
Scatter the powder seasoning on the food, The roller will mix the fat and seasoning powder evenly. Make food nice taste.
Stainless steel material(1.5mm thickness)
There are five fans on the top of the belt, they blow the food to make the temperature reduce to suitable for packing
Stainless steel material
98.8% Response Rate
98.8% Response Rate
99.6% Response Rate
is suitable for various meat paste and can produce different shapes, size and thickness by changing mould.
FIsh feed machine floating fish feed pellet machine food forming special equipment. The finished food can be fried by FIsh feed machine floating fish feed pellet machine, freezed or directly sell. Also can combined with pulping machine, crumbs coating machine and frying to form one production line. has reasonable design, easy to clean and simple operate, safe.
FIsh feed machine floating fish feed pellet machine is widely used for producing grains into high grade aquatic feed pellets for fish, catfish, shrimps, crab etc. can float on the water surface without dissolution for over 12 hours. According to FIsh feed machine floating fish feed pellet machine customer's requirement and production scale, can be classified into dry type machine and wet type machine.
is mainly used for fried beefsteak and drumstick as frying dressing .The long and sliver-shaped breadcrumbs made by are of porous structure inside .After frying of FIsh feed machine floating fish feed pellet machine.the crumbs become straight up bit by bit.FIsh feed machine floating fish feed pellet machine are not only puffed and nice in appearance but also foods made by is crisp and delicate in taste.
