Product Description

Big floating fish feed pellet extruder machine

Big floating fish feed pellet extruder machine introduction

Pet feed pellet machine is widely used for producing grains into high-grade aquatic feed pellets for fish, catfish, shrimps, crab,cat,dog,etc. The puffing pellets can float on water surface for over 12 hours,.According to your capacity and material ,We wil suggest you different model fish feed pellet machine.

Big floating fish feed pellet extruder machine working principle

Feed material by feeding device, it will be pressed by the screw shaft under high pressure and temperature which makes the raw material fully puffed . Pellets can be different shape and size by changing the mold . Then cutting blades will cut the pellets into different length .

Big floating fish feed pellet extruder machine features

1.Main parts adopt special alloy steel,dealed by heat treatment,long life time than usually machine.

2.Mold can be change easily ,can met different fish,shrimp,etc.

3.Without any adhesive.Floating fish feed can keep floating for more than 12hours without resolve, The floating time can be controlled by the puffing degree adjustment.

4.Adopt electric heating system improve feed expansion rate and delay the pellets floating time.

5.High temperature puffed process can kill the salmonellosis and bacterial infections,mean while make pellets easily digested.

6.Different of dry type and wet type floating fish feed pellet machine :

Wet fish feed pellet machine need boiler to supply steam,dry type don’t need boiler.

Dry type more cheaper than Wet type .

Wet type can produce much smooth and better quality feed pellet .

Dry type Big floating fish feed pellet extruder machine specification

Model

Capacity

(kg/h)

Power

(kw)

Screw diameter

(mm)

Cutting power

(kw)

DGP60-C

120-150

15

φ60

0.4

DGP70-B

180-200

18.5

φ70

0.4

DGP80-B

200-250

22

φ80

0.6

DGP90-B

300-350

37

φ90

0.8

DGP120-B

500-600

55

φ120

2.2

DGP135-B

700-800

75

φ133

2.2

DGP160-B

1000-1200

90

φ155

3.0

DGP200-B

1800-2000

132

φ195

3.0-4.0

Dry type Big floating fish feed pellet extruder machine photos

Wet type Big floating fish feed pellet extruder machine specification

Model

Capacity

(kg/h)

Power

(kw)

Feed power (kw)

Screw diameter

(mm)

Cutting power

(kw)

Conditioning power(kw)

DSP60-B

180-200

15

0.4

Φ60

0.4

0.75

DSP70-B

250-300

18.5

0.6

Φ70

0.6

0.75

DSP80-B

350-400

22

1.1

Φ80

0.8

1.1-1.5

DSP90-B

500-600

37

1.1

Φ90

1.1

2.2

DSP120-B

700-800

55

1.1

Φ120

1.5

2.2-3.0

DSP135-B

1000-1200

75

1.5

Φ135

2.2

3.0-4.0

DSP160-B

1800-2000

90

2.2

Φ155

2.2-3.0

4.0-5.5

DSP200-B

3000-4000

132

2.2

Φ195

3.0-4.0

5.5

Photoes of wet Big floating fish feed pellet extruder machine (With moisture modulator)

DSP60-B

DSP70-B,80-B,90-B,120-B-135-B,160-B

Finished fish feed pelllet

Pet food (cat,dog)

Welcome to know our Big floating fish feed pellet extruder machine .

...

is suitable for various meat paste and can produce different shapes, size and thickness by changing mould.
ce certificated big floating fish feed pellet extruder machine food forming special equipment. The finished food can be fried by ce certificated big floating fish feed pellet extruder machine, freezed or directly sell. Also can combined with pulping machine, crumbs coating machine and frying to form one production line. has reasonable design, easy to clean and simple operate, safe.

ce certificated big floating fish feed pellet extruder machine is widely used for producing grains into high grade aquatic feed pellets for fish, catfish, shrimps, crab etc. can float on the water surface without dissolution for over 12 hours. According to ce certificated big floating fish feed pellet extruder machine customer's requirement and production scale, can be classified into dry type machine and wet type machine.

is mainly used for fried beefsteak and drumstick as frying dressing .The long and sliver-shaped breadcrumbs made by are of porous structure inside .After frying of ce certificated big floating fish feed pellet extruder machine.the crumbs become straight up bit by bit.ce certificated big floating fish feed pellet extruder machine are not only puffed and nice in appearance but also foods made by is crisp and delicate in taste.
