2018 china stainless steel breakfast cereals corn flakes making machine

2018 china stainless steel breakfast cereals corn flakes making machine

Product Description 1 . China new products breakfast cereals processing line are a kind of breakfast with high nutritional value. They usually use corn...
  • Negotiation | Get Latest Price
  • 20000*1200*2200mm
  • Within 5 working days
  • paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
  • 64
  • Original 2018 china stainless steel breakfast cereals corn flakes making machine
  • SBN
  • ISO9001
  • SLG65/70/85

Product Description

Product Description

1.China new products breakfast cereals processing line are a kind of breakfast with high nutritional value. They usually use corn powder and other cereals as main raw material, through mixing, extruding, flaking, drying, baking, coating and cooling, to get crispy flakes. It always service as breakfast cereal mixed with milk of coffee. But it can also be a kind of leisure snacks. This process line can also make other shapes of cereals such as rings, balls, chocos, curls etc
2. Raw materials :

corn powder and other cereals
Products :

corn powder and other cereals
. Capacity :

5. Flow chart:

Mixing ---Extrusion ----cooling---cutting- --drying
6. Voltage in China

Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers' Local voltage according to different countries
7. Machines Materials

All the machines are made by 304 stainless

8.Specification of the China new products breakfast cereals processing line:

Model SLG65 SLG70 SLG85
Install Power 65KW 110KW 190KW
Consumption Power 42KW 77KW 133KW
Output 120-150KG/H 220-260KG/H 500-600KG/H
Dimension 19000×1300×2200M 22000×1300×2200M 30000×1300×2500M

Jinan Saibainuo Machinery Co., Ltd for food machine manufacutrering in China since 2004, offer competitive advantage machines, so with us your money in safe, your business in safe.

Our extruder details.

Detailed Images

Name: high speed mixer

Dimension(m): 1.1×0.8×1.4
Motor Power: 4KW
Speed: 400rpm
Throughput: 25kg per loading (5-6 minutes per loading)
mix raw powder material with water
1. stainless steel material(1.5mm).
2. new handle-opened design of discharge holes,no material leak
3.High speed can mix material better than other slow mixer.

Name: screw conveyor

Dimension(m): 3.2×0.6×0.7
Motor Power: 1.1KW
Screw speed: 300rpm
convey height range:1.5~2.5M
barrel diameter: Φ141mm
Power material can be conveyed in the stainless steel roller to the feed machine of extruder without leaking, dust and pollution; feed quantity is even and stable.
stainless steel material(1.5mm) and advanced surface spraying handle.

Name: twin screw extruder

Dimension(m): 2.4×1.0×1.3
Main Motor Power:22KW
Feeder motor:0.75kw
Cutting motor: 1.5kw
Heating power:10kw
Extruder diameter:Φ65 mm
Extrude and cook raw material into different size and shapes
Screw material is 38CrMoAl with nitriding treatment, the
hardness is 60HRC.. The barrel also use good material, hardness is 55HRC.
The gear box has forced lubrication system.
All motors can be adjusted the speed by Inverter.
The Extruder can change different molds to produce different Shapes product.

Name: dryer(we also have gas/diesel/steam dryer for your selection)

Dimension(m): 5.4×1.3×1.8
Heating Power:27kw
Motor power:0.75kw
Belt speed:0.1-10M/minute
Temperature: 20-200℃
There are three layer inside,each layer is 5 meters long, it can save space and energy. Electricity heating,used to bake and dry food.
The net belt running speed can be controlled by Inverter, to change the food drying time in the dryer.
Heating adopts the electric heat tube.
It has automatic temperature Control system.
The belt and the cover are all stainless steel

Name: flavoring line

Dimension(m): 3.8×0.8×1.8
Motor Power: 1.5KW
Scatter the powder seasoning on the food, The roller will mix the fat and seasoning powder evenly. Make food nice taste.
Stainless steel material(1.5mm thickness)

Name: cooling conveyor

Dimension(m): 5.0×0.7×1.1
Motor Power:1 KW
Cool the pet food after flavoring ,make the pet food suitable for packing.
Stainless steel material
Have fan and baffle,better cooling and no leakage
