Product Description

Product DescriptionIndustrial Automatic Peanut Butter Production Line


Flow chart of peanut butter production equipment :

Roasting---Cooling--Peeling--Selecting --Milling--Mixing--Cooling--De-gasing-- fillingwidth: 750px; height: 312.5px; margin-left: 0px; margin-top: 0px;

Instruction of Commercial peanut butter production line:

Roasting:
Batch roaster’s working temperature is 200-210 ºC, 20-30 minutes. Use batch roaster will bake some delicious smells.
Cooling:
Peanut will be send cooling belt to cool.
Peeling:
Put the roasted peanuts into peeler to take off the red skin, the double rollers will frication the red skin, the simple cyclone system will suck the red skins, most of them will be put in half-piece, then fall to the selecting conveyor, the over-roasted andun-blanched peanut kernel is picked up by manual or mechanical.

Primary grinding:
Using steel grinder to make the first grinding.
Second grinding:
Using colloid grinder to make the second grinding, the fineness of grinding is controlled below 7μm, temperature of grinding is controlled below 68C.
Mixing:
Make the butter more homogeneous.
Cooling:
The butter through second grinding should be cooled immediately. The temperature should go down 45C.
De-gassing:
Take out the air from peanut butter.
Storage tank:
Settling down in the storage tank till the temperature drop to air temperature.
Packing:
By the filling machine, the finished peanut butter is packed into 200g/500g/1000g bottle.

Technical Data of Peanut Butter Production Line
Style capacity
(kg/h)
Power(kw) Material Voltage
Dimension(m)
HSJ-200
100-200 20-30 stainless steel 304 380v /220v 10*2.7*2.2
HSJ-400 300-400 50-60 stainless steel 304 380v /220v 20*4.7*4.2
HSJ-500 500-800 90-100 stainless steel 304 380v /220v 35*4.7*4.2
width: 849.333px; height: 320px; margin-left: -51px; margin-top: 0px; width: 408.833px; height: 200px; margin-left: -12px; margin-top: 0px; width: 371px; height: 494.667px; margin-left: 0px; margin-top: -141px; width: 426.667px; height: 320px; margin-left: -48px; margin-top: 0px; width: 426.667px; height: 320px; margin-left: -24px; margin-top: 0px;Related Productswidth: 371px; height: 371px; margin-left: 0px; margin-top: -15px; width: 408.1px; height: 408.1px; margin-left: -26px; margin-top: -36px;

Multi-Application Peanut Nuts Roasting Machine (Continuous,Large Output )

Multi-Application Peanut Nuts roaster

(Batch, Small Output)

width: 448.8px; height: 448.8px; margin-left: -62px; margin-top: -91px; width: 448.8px; height: 448.8px; margin-left: -45px; margin-top: -69px;

Roasted Peanut Peeling Machine (Continuous, Large Output )

Wet type Peanut Peeling Machine (Continuous, Small Output )

Production Process

Experienced Mechanics

width: 750px; height: 500.25px; margin-left: 0px; margin-top: 0px;

Professional Manufacturing Facilities

width: 750px; height: 500.25px; margin-left: 0px; margin-top: 0px;Packing & Deliverywidth: 750px; height: 409.869px; margin-left: 0px; margin-top: 0px; width: 371px; height: 371px; margin-left: 0px; margin-top: -32px; width: 480px; height: 320px; margin-left: -37px; margin-top: 0px;About USwidth: 726px; height: 220px; margin-left: -355px; margin-top: 0px;

Factory supplied Peanut butter Production Line, Peanut Butter Making Machine Line, Peanut Paste Making Machine Factory supplied Peanut butter Production Line, Peanut Butter Making Machine Line, Peanut Paste Making Machine Food Machinery Manufacturing Co., Ltd.

Established in 1993 and situated in Qixia of Factory supplied Peanut butter Production Line, Peanut Butter Making Machine Line, Peanut Paste Making Machine City, Shandong Province with a registered capital of 2,000,000 RMB and an area of 9,800 square meters, is a professional food machinery manufacturing company integrated with R&D, professional manufacturing, direct sales and after sales service.


We have taken lead in issuing and passing Shandong Business Product Quality Standard and have been smoothly certified to ISO9001:2008 International Quality Management System, CE safety certification for exporting to European Union, BV certification, the third party certification. Now we have successfully gained trademark.

width: 367.4px; height: 347.6px; margin-left: 0px; margin-top: -76px;Certificationswidth: 750px; height: 587.264px; margin-left: 0px; margin-top: 0px;Our Customerswidth: 547.2px; height: 547.2px; margin-left: 0px; margin-top: 0px; width: 607.5px; height: 497.7px; margin-left: 0px; margin-top: 0px; width: 607.5px; height: 467.1px; margin-left: 0px; margin-top: 0px;Contact Personwidth: 675px; height: 448.2px; margin-left: 0px; margin-top: 0px;
