Factory Direct Sales Of High Quality Packing Machine Snack

Microwave popcorn packing machine, rotary packing machine for microwave popcorn pouch packing machines. Microwave Popcorn Filling Packing Machine (Automatic Packing...
  • INFO@LDFOODMACHINE.COM | Get Latest Price
  • 4350*2000*3700mm
  • Check with us
  • paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
  • Contact with us
  • China
  • Corn Nuts Snacks machine
  • CE
  • Corn Nuts Snacks machine

Product Description

Microwave popcorn packing machine, rotary packing machine for microwave popcorn pouch packing machines.

Microwave Popcorn Filling Packing Machine (Automatic Packing Machine)

Popcorn Packaging Sample:

Application: WT6/8-200/300-S Rotary Weighing & Packaging Line for Solid (or Grain) rotary packing machine composited by rotary packing machine, combination weigher and Z- shaped Conveyor, which is suitable for packing all kinds of grains and solids, such as candy, nuts, raisins, peanuts, melon seeds, nuts, potato chips, chocolate, biscuits and so on.

Production Process:

1. Feeding bag

2. Open bag

3. Open bag and Fold upside of the bag

4. Feeding(popcorn and cream)

5. Sealing 1st and folding underside of the bag

6. Sealing 2nd and forming & outputpackages

Standard Configuration:

  1. PLC control system.
  2. Pneumatic components
  3. Temperature control system
  4. Factory Direct Sales Of High Quality Packing Machine Snack pump
  5. Output device

Optional Configuration:

  1. Rotary packing machine.

It is optional to choose WT6/8-230 rotary packing machine. Only one minute is needed to adjust the machine splint.

  1. Computer combination weigher
  2. Material conveyor
  3. Working platform
  4. Vibration system
  5. Exhaust or inflatable structure
  6. Pressure feeding system
  7. Equipment for bag feeding flatly
  8. Metal detector

10.Weight sorting scales

11.Product conveyor

12.Processing tray

Main Advantages:

  1. To reduce production cost and administration cost. One packing line can deduct 4-10 workers. Investment cost can return with 1-2 years.
  2. Product quality is improved. The products achieve uniform standard from its appearance or packaging quality.
  3. To reduce the defect rate. Qualified product rate reaches 99.5% to avoid artificial packaging waste.
  4. To improve health standard. The packaging process without direct contact with people to avoid man-made pollution.
  5. The use of combination weigher to get accurate measurement, to avoid too much more raw, to save raw material and cost.

Main Performance and Features:

  1. A wide range of materials can be packed. E.g.: kinds of shapes, state, or natures of particles and lumps.
  2. Easy to operate. It adopts PLC control, human-machine interface operating system, to make the operation easy and intuitive.
  3. Convenient to adjust. The replacement of species can be completed within 10 minutes.
  4. Suitable for different types of bags or pouch.
  5. A sound prevention system to protect qualified product rate, to avoid waste of bags or materials.
  6. The pack machine parts made of stainless steel, to ensure the health and safety of materials and products.
  7. High degree of automation. The whole process of weighing and packaging is unmanned operation. Automatic alarm system is adopted too.
  8. Some imported engineering plastics without refueling, to reduce the pollution of materials.
  9. Oil-free Factory Direct Sales Of High Quality Packing Machine Snack pump is adopted to avoid contamination of the production environment.

Main Technical Parameters:

6-Station Rotary Weighing & Packaging Line for Solid (or Grain)

Model

WT6-200-S

WT6-230-S

WT6-300-S

Pouch Type

Flat bag, 3-side sealing bag, 4-side sealing bag, zipper bag, standup bag etc…

Pouch Material

Laminated film, PP, PE etc…

Pouch size

W:80-210mm L:150-300mm

W:80-230mm L:150-300mm

W:150-300mm L:150-300mm

Packing weight

5-1500g

5-1500g

5-1500g

Packing Speed

20-55 Bags/Min (depends on the packing material and filling weight)

30-55 Bags/Min (depends on the packing material and filling weight)

20-45Bags/Min (depends on the packing material and filling weight)

Packing Accuracy

≤±1%

≤±1%

≤±1%

Power

3.5KW,AC380V,50Hz

3.5KW,AC380V,50Hz

4.2KW,AC380V,50Hz

Air Consumption

0.3m3/min

0.3m3/min

0.3m3/min

Overall Dimensions (L*W*H)(mm)

4200*2000×3700

4340*2000×3700

4600*2200×3700

8-Station Rotary Weighing & Packaging Line for Solid (or Grain)

Model

WT8-200-S

WT8-230-S

WT8-300-S

Pouch Type

Flat bag, 3-side sealing bag, 4-side sealing bag, zipper bag, standup bag etc…

Pouch Material

Laminated film, PP, PE etc…

Pouch size

W:80-220mm L:150-300mm

W:80-230mm L:150-300mm

W:150-300mm L:150-300mm

Packing weight

5-1500g

5-1500g

5-1500g

Packing Speed

20-50 Bags/Min (depends on the packing material and filling weight)

30-60 Bags/Min (depends on the packing material and filling weight)

15-45 Bags/Min (depends on the packing material and filling weight)

Packing Accuracy

≤±1%

≤±1%

≤±1%

Power

3.85KW,AC380V,50Hz

3.85KW,AC380V,50Hz

4.5KW,AC380V,50Hz

Air Consumption

0.3m3/min

0.3m3/min

0.3m3/min

Overall Dimensions (L*W*H)(mm)

4350*2000×3700

4650*2350×3750

4650*2350×3750

Packing Process:

Equipment Drawing:

Machine Photos:

Other complete packaging lines for liquid or thick-liquid, power, granules, grain, or solid, are available:

,Kurkure Making Machine/Crispy Corn Curls Maker form the highest quality extruded collets from corn grits can produce kurkure, niknaks, cheetos,cheese corn curls etc. Cheetos Extruder of is for extrusion and shaping, Other accessories will be allocated based on customers' requirement.Find here Factory Direct Sales Of High Quality Packing Machine Snack manufacturers, suppliers & exporters in China,Get contact details & address of companies manufacturing and supplying Factory Direct Sales Of High Quality Packing Machine Snack.

The can be combined or separated.Factory Direct Sales Of High Quality Packing Machine Snack is our new design which integrates the European Technology and Utility. is a breakthrough to solve the problems regarding to sticky material on the roller,low output of flakes pressing ,low shaping rate ,poor taste.Find here Jinan Joysun Machinery Co., Ltd. manufacturers, suppliers & exporters in China,Get contact details & address of companies manufacturing and supplying .

Factory Direct Sales Of High Quality Packing Machine Snack is one business of hot products in Food Extruder Machine industy.Jinan Joysun Machinery Co., Ltd. are a large-scale company specializing in all kinds Of ,peanut and Sesame Related Machine,Find here FF manufacturers, suppliers & exporters in China,Get contact details & address of companies manufacturing and supplying .
