Home >  Asian snack Food Processing Machinery Manufacturer >  large capacity automatic extrusion food processing machine
large capacity automatic extrusion food processing machine large capacity automatic extrusion food processing machine large capacity automatic extrusion food processing machine

large capacity automatic extrusion food processing machine

Extrusion Systems Production Line of Snack Pellets HX Extrusion Systems Production Line of Snack Pellets can be used...
  • INFO@LDFOODMACHINE.COM | Get Latest Price
  • 18590*2000*2400mm
  • Check with us
  • paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
  • Contact with us
  • China
  • Asian snack Food Processing Machinery Manufacturer
  • CE ISO9001
  • Asian snack Food Processing Machinery Manufacturer

Product Description

Extrusion Systems Production Line of Snack Pellets
HX Extrusion Systems Production Line of Snack Pellets can be used with a very wide range of raw materials such as potato starch, potato powder, tapioca, wheat flour, etc. This production line is consist essentially of several machines in different functions as a completed production line in actual operation. The main machine of this production line is the JY-Pellet Extruder which is with 2 dimensions for small or big scales of extrusion processing as customers’ selection. We could also re-adjust the design and function for customers if necessary.

Model

Output

Complete Line Power

Dimension

JY-60

60 kg/h

53kw

28000mmL*3100mmW*2980mmH

JY-120

120 kg/h

68kw

29750 mmL*3100mmW*2980mmH

Auto System

240kg/h

114kw

32950 mmL*3100mmW*2980mmH

Flow Chat

vertical-align: middle;

Main Machine Details

CLICK THE MACHINE PHOTO TO GET MORE DETAIL
vertical-align: middle;

SF-Screening Machine

FUNCTION: Screening the material to keep safety.
DRIVE POWER: 0.55 KWH
CAPACITY: 5000KG/Hr
DIMENSION: L-1830mm, W-720mm, H-1050mm
WEIGHT: 225KG

SL-Wetting Machine

FUNCTION: Mixing the material with water.
DRIVE POWER: 1 KWH
CAPACITY: 140KG/Hr
DIMENSION: L-1750mm,W-1050mm,H-1620mm
WEIGHT: 225KG

vertical-align: middle;

vertical-align: middle;

JY-Pellet Extruder

FUNCTION: Produce the snack pellet, through different die can get different shape snack.
DRIVE POWER: 30 KWH (JY-60)
CAPACITY: 60KG/Hr(JY-60)
DIMENSION: L-3450mm,W-930mm,H-2340mm
WEIGHT: 3295KG

JYP-Pellet Slicer

FUNCTION: Slicing the pellet to required shape
DRIVE POWER: 1.5 KWH
CAPACITY: 60KG/Hr
DIMENSION: L-750mm,W-600mm,H-1050mm
WEIGHT: 185KG

vertical-align: middle;
vertical-align: middle;

JYX-Angle Cutting Machine

FUNCTION: Slicing the pellet to required shape.
DRIVE POWER: 1.5 KWH
CAPACITY: 60KG/Hr
DIMENSION: L-2860mm,W-700mm,H-1200mm
WEIGHT: 475KG

3600S-Drying Machine

FUNCTION: Drying the pellet to reduce the moisture.
DRIVE POWER: 12 KWH
CAPACITY: 200KG/Hr
DIMENSION: L-9300mm,W-3100mm,H-2980mm

vertical-align: middle;
vertical-align: middle;

300S-Batch Fryer

FUNCTION: For frying the snack pellet.
DRIVE POWER: 4 KWH
CAPACITY:120KG/Hr
DIMENSION: L-4550mm,W-1980mm,H-2020mm
WEIGHT: 2230KG

NZ180-Continuous Seasoner

FUNCTION: For flavoring the snack
DRIVE POWER: 1.75 KWH
CAPACITY: 120-200KG/Hr
DIMENSION: L-3200mm,W-930mm,H-2050mm
WEIGHT: 560KG

vertical-align: middle;
Main Electrical Comp

Transducer

Temperature controller

Travel switch

AC contactor

Delta

Fuji

Schneider

Schneider

Relayer

Breaker

Indicator

Knob switch

Schneider

Merlingerin

Schneider

Schneider

Customer List

vertical-align: middle;

Certificates

vertical-align: middle;

Company

vertical-align: middle;

Shantou Huaxing Machinery Factory Co., Ltd is a professional manufacturer for snack machinery.We started to produce the snack machines around 38 years ago.We have sold our machines to over 45 countries already. We have obtained ISO9001:2000 certificate. Some of machine ,we have abtained CE certificate.We welcome customers from all over the world to cooperate with us , if you are interested in any of our series, please do not hesitate to contact us of details.

vertical-align: middle;

Our Service

Pre-sales service:

1. Related machines’s technical parameter supplied.
2. Production line layout can be provided in advance According to customer building space.
3. Suggesting professional shipping line or book the container as customer request.

After sale service:

1. Training how to instal the machine, training how to use the machine.
2. Engineers available to service machinery overseas.
3. Free easy broken spare parts will be sent with container .

vertical-align: middle;

1.Are you a manufacturer or a trading company?
We are a professional manufacturer of food machinery.Especially for large capacity automatic extrusion food processing machine processing production line.

2.What's the price of your machines?
You can inquiry to us directly.

3.What is your payment terms?
T/T or L/C; by T/T 30% as down payment, 70% by T/T before delivery, L/C at sight.

4.Can we provide the formula to you?
We can provide basic formula .
And help customer to produce good quality food according customer’s detailed formula.

5.What is the workshop size required?
The production line can be put in straight line and also can change the direction according to your factory size.We can design the layout according to your factory size.

vertical-align: middle;

,Kurkure Making Machine/Crispy Corn Curls Maker form the highest quality extruded collets from corn grits can produce kurkure, niknaks, cheetos,cheese corn curls etc. Cheetos Extruder of is for extrusion and shaping, Other accessories will be allocated based on customers' requirement.Find here large capacity automatic extrusion food processing machine manufacturers, suppliers & exporters in China,Get contact details & address of companies manufacturing and supplying large capacity automatic extrusion food processing machine.

The can be combined or separated.large capacity automatic extrusion food processing machine is our new design which integrates the European Technology and Utility. is a breakthrough to solve the problems regarding to sticky material on the roller,low output of flakes pressing ,low shaping rate ,poor taste.Find here Jinan Joysun Machinery Co., Ltd. manufacturers, suppliers & exporters in China,Get contact details & address of companies manufacturing and supplying .

large capacity automatic extrusion food processing machine is one business of hot products in Food Extruder Machine industy.Jinan Joysun Machinery Co., Ltd. are a large-scale company specializing in all kinds Of ,peanut and Sesame Related Machine,Find here FF manufacturers, suppliers & exporters in China,Get contact details & address of companies manufacturing and supplying .
