Product Description

Puff snacks food processing machineProduct Description

Corn snacks food extruder machine adopt corn, rice, wheat, oat, barley etc as ingredients to make puffed snack. Through friction of screw and barrel, the grains are cooked in the extruder. Forming is at the die face cutter. The product shape is determined by a combination of the die aperture, including ball, tube, stick, ring, fruit loop, star, wheel and flower etc.

2. Snacks Raw materials:
Corn, rice, millets, wheat, oat, barley etc as ingredients. Please note that all the materials should be in powder(flour) or grits form.
3. Snacks food Products shapes:
Variety shapes are available for ball, tube, stick, ring, fruit loop, star, wheel and flower and heart shape by adjusting the mould in the extruder

Our Puff snacks food processing machine processing line machine produce sample:


4. Puff snacks food processing machine Flow chart:
Mixing system---Twin screw Extrusion system----Drying system----Flavoring system--Packing system

Mixer Function and Features:

Mixer makes the raw material which adding water and liquid chemical additive fully mixed equally. the machine mixes the flour and prepares them ready to be used in the next step.
1. Surface which touches mixer and raw material adopt stainless steel;the mixer is easy to operate it.
2.The discharge hole adopts the new handle-opened design, good seal and avoids leaking the material
3. we can choose different install powder mixer to meet the extruder capacity require.

width: 243.9px; height: 233.1px; margin-left: 0px; margin-top: -9px;

Double screw food extruder Features:

1. Alloy (38CrMoAL) screw made by nitriding process, high strength and wear-resting. Self-cleaning ability, no need to discharge or clean the barrel and screw when roasting or replacing of materials.
2. Adopting speed-adjusted converter on feeding system, extrusion system and cutting system. Food grade stainless steel twin screw feeding machine, stable materials feeding in the whole food process.
3. Gearbox with automatic lubrication function, extending gear life.

Extruder parts:

Nitriding treatment(120 Hours)
Depth of Nitrided Layer: 0.5-0.8 mm
Hardness of Nitrided Layer: 950-1100Hv (HRC56°-65°)
Chrome Plating
Thickness of Hard Chrome Plating Layer: 0.05-0.10mm
Wear sleeve and screw sleeve are made of high wear-resistant alloy steel, to reduce abrasion and prolong service life.

Machine Parts: dryer

1. This dryer has the compact structure, small occupying, large drying area, small surface area, slight radiating heat and high thermal efficiency.
2.The belt and the heat preservation use the stainless steel; it is suitable for food safe industry level.

3.The running speed of belt net can be controlled (frequency controlling system)

5.Puff snacks food processing machine Capacity:

Our this processing line capacity from 100-1000KG/H.you can follow u requirement choose it.

60-80kg/h 100-150kg/h, 200-240kg/h, 500kg/h 800kg/h 800-1000kg/h.

Steam Model Install power Consumption Main Power Capacity Diemension
SLG65 30.0kw 22-30kw 22.0kw 120-200kg 15*2.5*4.0M
SLG70 35.0kw 25-40KW 30.0kw 250-400kg 27*2.5*4.5M
SLG75 45.0kw 40-50KW 45.0kw 300-500kg 27*2.5*4.5M
SLG85 80.0kw 100-200kw 75kw 350-550kg 30*1.5*2.4
SLG90 100.0kw 100-135kw 75kw 800-1000kg 40*1.5*5.0
Company Information

Jinan Datong Machinery Co., Ltd is a professional food machinery manufacturer in Jinan city shandong province China.Our company congregates an exceptional food machine engineering team, personal customer service center and highquality manufacturing capabilities have evolved exponentially,We are working hard on explore constantly not only in the research of extrusion technology, but also in food technics to benefit our clients producing newfangled food in their markets. It making us become one of the preeminent providers of reliable extrusion equipment world-wide.

Our Services

1. Free consultation service before, during, and after sales;
2. Free Project planning and design services upon clients' special demands;
3. Debugging and inspecting of equipment until everything is functional before leaving the factory;
4. Overseas installation and training of equipment maintenance and operating personally;
5. Provide basic production techniques and formulas;
6. 1 year complete warranty for Extruded Food Wheat Corn Snack Pellet Making Machine

Workshop &customer

Packaging & Shipping

Packing: inside plastic bag, outside wooden case for Extruded Food Wheat Corn Snack Pellet Making Machine (Based on the customers' need adopt the wooden case or wooden pellets, etc.).
Transportation: shipping, train, express or upon clients' demands.

vertical-align: middle;

vertical-align: middle;


Q: How long is your delivery time?

A: Generally it is 7-10 days if the goods are in stock. or it is 20-25 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?

A: 40% T/T in advance ,balance before shippment.If you have another question, pls feel free to contact us as below.

Contact Us

If u want to know more please feel free contact me and send me inquiry now.

vertical-align: middle; color: #000000; font-family: Arial; font-size: 12px; font-style: normal; font-weight: normal; background-color: #ffffff; width: 695px; height: 458px; margin-left: 0px; margin-top: 0px;

uses the deffatted soya/peanut flour as the raw materials. By high temperature and presser,Jinan Joysun Machinery Co., Ltd. the materials can reorgnized and shaped into different shapes by Puff snacks food processing machine , such as pipe, stick,ball, pellets, pillow and so on. As the line make more concentrated and healthy protein, has become the most popular line in all the world.

Puff snacks food processing machine relies on additional energy being supplied that’s preferentially absorbed by the solvents in the process to enhance evaporation Jinan Joysun Machinery Co., Ltd. . are a form of electromagnetic energy (300 Mhz–300 GHz), Puff snacks food processing machine generated by magnetrons under the combined force of perpendicular electric and magnetic fields by .

This mixer Puff snacks food processing machine is three layers and including cooling, heating and heating insulation. is mainly suitable for preparation of foodstuff.Jinan Joysun Machinery Co., Ltd. pharmacy and liquid detergents (such as liquid soap,cleanser essence, shampoo and shower cream etc.).Puff snacks food processing machine Integrating blending, homogenizing dispersing, heating and cooling etc functions, the reacting machine is an ideal device for liquid preparation in various factories.
