Product Description

Product DescriptionProduct Description

Characteristics of YZYX70ZWY

1. Healthy!Physical squeezing craft maximally keeps the nutrients such as the protein, fatty acids and minerals, etc.

2. High working efficiency! The spiral squeezing structure can achieve high oil output, thus the oil content of the residue cake is low.

3. Long durability! All the parts are made of the most suitable material and treated with refined crafts to ensure the long term runing, such as cemented quenching and tempering to increase the hardness, consequently the durability.

4. Cost-effective! The wearing parts on the machine such as the squeeze loop, squeeze spiral and squeeze bar are designed to be dismountable. When they are out of service period, users only need to replace them and no need to displace the whole machine.line-height: 14.4px; color: #000000; font-family: Arial; background-color: #f5f5f5;

Advangages

vertical-align: middle;

1. More than 30 years of experience in manufacturing oil press.

2. 7 patents of oil press technology.

3. Full inspection before delivery, quality pass rate more than 98%.

4. More than 300 professional workers. 10% of them are mechanical engineers technicians.

5. Widely used in our life, have been exported to more than 70 countries.

Products show detail:

vertical-align: middle;

The YZYX70ZWY integration oil press is a new environmental friendly product developed on the basis of single machine after we investigated the market demand. It was added with frying and auto heating of the press chamber. The function of auto-heating the press cage has replaced the traditional way by squeezing residue cake, which could shorten the preparation work, reduce the energy consumption and machine’s abrasion, consequently lengthen the service life. When the squeezing is suspended, the temperature can be maintained automatically. In the meanwhile, this machine was added with more functions and the degree of automation is increased, changing the single machine to combined machine with frying, squeezing and filtration functions in one. The seeds after fried directly go to the squeeze chamber to be squeezed. At the same time, the extracted crude oil will directly be filtrated by the automatic temperature control integration small oil press combined with frying pan filtration machine. Comparing with the traditional plate frame filtration machine, the automatic temperature control integration small oil press combined with frying pan filtration machine is lighter, easier to operate and more convenient to clean the residue (so the residue can be re-squeezed in time if necessary). The structure of this combined oil press is compact, only requires a small working place and saves labor. It is ideal equipment for processing oil lively at supermarket, grain oil shop and farmers market.

vertical-align: middle;

The automatic temperature controlled integration oil press made by our company is suitable for squeezing many kinds of top grade vegetable oil, such as sesame seeds, groundnut and sunflower seeds, etc. It has advanced design-combined with frying, squeezing and filtration in one, easy to operate and the oil output is high.

The product conforms to the “Technology Standard of Agricultural Spiral Oil Press” under JB/T9793·1-1999 of the People's Republic of China.

working state

vertical-align: middle;

Company Information

vertical-align: middle;

vertical-align: middle;

Packaging & Shipping

vertical-align: middle;

FAQ

1. Delivery time.

---20~30 days after order confirmation. We need time to prepare machine according to exporting standard, wear-in, making wooden box, fumigation and suitable ship arrangement from forwarder.

2. If I don't know how to operate this machine? how can I do?

----Our machine has been tested OK and fully assembled before shipping, customer just needs to make2~4 hours wear-in and then can work.

3. Why Feeding blocked and no oil comes out?

1. The work-sections of squeeze loops and squeeze spirals are coarse.

2. Oil plants in the press chest mixed with oil.

3. Gaps between the squeeze bars and oil grooves on the squeeze loops are blocked.

4. Oil plants have high oil content; need more oil channels to discharge the oil.

5. Oil plants are too dry when press in hot way.

4. What is the Moisture and temperature of oil plants to press? (For reference)

Items

Rapeseed

Groundnut

Cotton seed

Tung seed

Soybean

(hot pressing)

Soybean

(cold pressing)

Moisture (%)

1~2

1~2

2~2.5

2~2.5

1.5~2.5

8~10

Temp. (°C)

130-135

120-125

120-130

110~120

120-125

Normal temp.

5. What is the main wearing parts and their replacement period?

Wearing parts

Replacement period

Squeeze loop & loop of the cake out

Run for 24hs, should replace 2 months

Squeeze spiral & spiral of the cake out

Run for 24hs, should replace 1 month

The accessory in the deceleration part

10000hs

Our Services

vertical-align: middle;

Sichuan Miautomatic temperature control integration small oil press combined with frying panng GuangXin Machinery of Grain & oil press company

Contact :Jesse

Tel/Whatsapp: +86 13698130339

automatic temperature control integration small oil press combined with frying pan +86 13698130339

QQ :287353551
