frying production line for peanut, beans snack frying production line for peanut, beans snack frying production line for peanut, beans snack

frying production line for peanut, beans snack

continuous fryer frying production line for peanut, beans snack Size: 3000*1150*2260mm Belt size: 1500*450mm Oil capacity: 300L Heating way: gas...
  • INFO@LDFOODMACHINE.COM | Get Latest Price
  • 4000*1350*1950mm
  • Within 5 working days
  • paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
  • Contact with us
  • China
  • Peanut Frying Machine
  • CE Certificate, CE
  • Peanut Frying Machine

Product Description

continuous fryer width: 964.7px; height: 675.4px; margin-left: -71.2px; margin-top: -429.6px;

frying production line for peanut, beans snack


Size: 3000*1150*2260mm
Belt size: 1500*450mm
Oil capacity: 300L
Heating way: gas /LPG/diesel/electricity
Heating power: 60kw
Gas consumption: 6-7 kg/h

Machine performance

 Machine construction in stainless steel
 Double stainless steel net belt
 The frying time and temperature can be adjusted.
 With the fryer dregs device it can filtering the dregs automatically while working.
 The belt can lift out of the fryer to be convenience washing.
 The machine will cut off electric and gas automatically and give an alarm when over temperature.
 Machine equipped with fire extinguishing devices.
 Leakage protection devices.
 All the mark and operating instructions are English.
 All the electrical parts are frying production line for peanut, beans snack, Schneider or Omron.

width: 371px; height: 289.009px; margin-left: 0px; margin-top: -41.8182px;
technical date DBS300 DBS400 DBS650
Size 3000*1150*1950mm 4000*1350*2300mm 6500*1350*2300mm
Belt size 1500*450mm 3200*650mm 3200*650mm
oil capacity 300L 420L 600L
weight 350kg 420kg 850kg
heating power 60kw 120kw 200kw
volotage 380V/50hz/3phase 380V/50hz/3phase 380V/50hz/3phase
temperature range ≤260℃ ≤260℃ ≤260℃
width: 497.344px; height: 365.05px; margin-left: 0px; margin-top: 0px; width: 244.656px; height: 182.269px; margin-left: 0px; margin-top: -8.18182px; width: 244.656px; height: 183.798px; margin-left: 0px; margin-top: 0px; width: 750px; height: 372.517px; margin-left: 0px; margin-top: 0px; width: 244.656px; height: 207.761px; margin-left: 0px; margin-top: 0px; width: 244.656px; height: 207.761px; margin-left: 0px; margin-top: 0px; width: 244.656px; height: 207.761px; margin-left: 0px; margin-top: -7.27273px; width: 234.091px; height: 200px; margin-left: 0px; margin-top: 0px; width: 224.467px; height: 200px; margin-left: -18.1818px; margin-top: 0px; width: 301.318px; height: 200px; margin-left: -40.9091px; margin-top: 0px; width: 246.002px; height: 200px; margin-left: -20px; margin-top: 0px; width: 225.225px; height: 200px; margin-left: -23.6364px; margin-top: 0px; width: 225.225px; height: 200px; margin-left: -3.63636px; margin-top: 0px; width: 225.225px; height: 200px; margin-left: -23.6364px; margin-top: 0px; width: 200px; height: 200px; margin-left: -2.72727px; margin-top: 0px; beans frying line width: 750px; height: 561.75px; margin-left: 0px; margin-top: -119.091px;



(Oil filter) (powder feeder)

Infeed conveyor -- fryer -- conveyor -- de-oiling machine -- seasoning machine -- conveyor

(oil tank)

Infeed conveyor -- convey the products into the fryer evenly

Fryer -- usually nut will fall down to the bottom of fryer while frying, so we using single net belt with high scraper to keep the products go ahead. In this way we can get the best quality products.

Oil filter-- this is our patent products using for filtering the sediment while frying

Conveyor-- convey the fried products into the de-oiling machine

De-oiling machine-- centrifugal de-oiling and continuous working, the de-oiling time can be adjusted, frequency conversion control speed, frequency conversion trig.

Seasoning machine-- continuous flavoring machine, we can adjust the tube speed and powder feeding speed to get the best mixing effect.

Powder feeder-- with electromagnetic vibration to powder, the speed can be adjusted and more evenly.

Conveyor-- convey the finished products to the next machine.

Package width: 371px; height: 278.655px; margin-left: 0px; margin-top: -21.8182px;

Packing


Packing by wooden cases


Delivery by ship from Tianjin port


Exhibitationwidth: 307.895px; height: 234px; margin-left: -5.45455px; margin-top: 0px; width: 290.683px; height: 234px; margin-left: -10.9091px; margin-top: 0px; width: 312px; height: 234px; margin-left: 0px; margin-top: 0px;




Factory information width: 266.667px; height: 200px; margin-left: 0px; margin-top: 0px; width: 266.667px; height: 200px; margin-left: -13.6364px; margin-top: 0px; width: 266.667px; height: 200px; margin-left: -63.6364px; margin-top: 0px; width: 266.667px; height: 200px; margin-left: -7.27273px; margin-top: 0px; width: 426.667px; height: 320px; margin-left: -9.09091px; margin-top: 0px; width: 481.203px; height: 320px; margin-left: -82.7273px; margin-top: 0px;

frying production line for peanut, beans snack uses broken paddy flour as raw material, and with extruding, drying and polishing procedures, the new rice have good shape with color shine. Also, 's various nutrition matters can be added as nutritional rice.The usage is same to natural rice,but more simple and convenient than before. frying production line for peanut, beans snack not only nutrition but also adapts to the fast rhythm of the modern life.

frying production line for peanut, beans snack is a kind of shape machine which can produce many kinds of unique design snacks and cookies dry base by squeezing out and taking shape the dough and has characteristics of modern techniques, compact structure, multifunction, simple operation etc. is one of the most ideal new type food machinery deeply welcomed by the masses of users and investors of market at present as well.

garlic processing machine line.Jinan Joysun Machinery Co., Ltd. offer garlic separate machine,garlic peeling machine, garlic slicing machine ,,garlic harvester machine etc. Now our frying production line for peanut, beans snack have sell to 40+ countries include Canada ,Austria ,India ,South Afraic etc.We promise we will supply good quality of frying production line for peanut, beans snack ,and meet your need of frying production line for peanut, beans snack.
