Professional Industrial Vacuum Drying Oven

Product Description Product Application This Drying Oven is suitable for the material anda product heating, solidification, drying and dehydration of drugs, chemicals,...
  • INFO@LDFOODMACHINE.COM | Get Latest Price
  • 1380*1200*2000
  • Within 5 working days
  • paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
  • Contact with us
  • China
  • Snack Food Drying Oven
  • CE Certificate
  • Snack Food Drying Oven

Product Description

Product Description

Product Application

This Drying Oven is suitable for the material anda product heating, solidification, drying and dehydration of drugs, chemicals, food, agricultural and sideline products, marine products, e.g. raw medicines, crude drugs, traditional Chinese medicines prepared in ready-to-use forms, extracturms, powders, granular drugs, packing bottles, pigments, dyestuffs, vegetables, melons and fruits, Professional Industrial Professional Industrial Vacuum Drying Oven Drying Ovens, plastic resins, electronic components and coatings

width: 750px; height: 750px; margin-left: 0px; margin-top: 0px;
SPECIFICATIONS
Model Drying Capacity (KG/LOT) Electric Power(KW) Fan Power(KW) Steam Consumed(KG/H) Drying Trolly Baking Trays Dimensions(L*W*H )mm
HOD-O 60 9 0.45 10 1 24 1380*1200*2000
HOD-I 120 15 0.45 18 2 48 2260*1200*2000
HOD-II 240 30 0.45*2 36 4 96 2260*2200*2000
HOD-III 360 45 0.45*3 60 6 144 2260*3200*2000
HOD-IV 480 60 0.45*4 80 8 192 4280*2200*2270
width: 750px; height: 750px; margin-left: 0px; margin-top: 0px;

Main Features

1) The hot sources can be steam, electricity, far infrared, or system+electricity. Customers can select one of the heat ways in accordance with practical conditions.

2) Temperature of operation: 50-140°C for steam heating, Maximum temperature will be 150°C.

3) 50-500°C for electricity or far infrared

4) There are automatic and computer control systems for customers selection

5) The normal pressure of system will be 0.2-0.8Mpa(2-8kg/cm2)

6) The equipped power of electric heater will be 15kw calculated with Model 1 and the preational power to used will be 5-8w/h

7) If have special requirement, please indicate in order

8) The price of non-standard oven shall be discussed additionally

9) If the operation temperature is more than 140°C or less than 60°C, please indicate in order.

10) The size of drying troll and tray is standardized. They can be exchanged each other.

width: 750px; height: 750px; margin-left: 0px; margin-top: 0px;Detailed Imageswidth: 318.6px; height: 318.6px; margin-left: 0px; margin-top: 0px;
Technical Date HOD-O
Evaporation area(m3) 7.1
Efficient Volume(m3) 1.3
Drying Capacity(kg/lot) 60
Steam Consumption(kg/h) 10
Radiator area(m3) 10
Electric Power(kw) 9
Fan Volume(m3/h) 3450
Fan Power(kw) 0.45
Our Servicewidth: 371px; height: 200px; margin-left: 0px; margin-top: 0px; width: 371px; height: 200px; margin-left: 0px; margin-top: 0px;

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Deliverywidth: 318.6px; height: 318.6px; margin-left: 0px; margin-top: 0px;
Packaging
Size 1400 (L) * 1250 (W) * 2050 (D)
Weight 900 kg



Packaging Details
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
Related Productswidth: 243.10000000000002px; height: 243.10000000000002px; margin-left: 0px; margin-top: 0px; width: 244.656px; height: 244.656px; margin-left: 0px; margin-top: -2px; width: 244.656px; height: 244.656px; margin-left: 0px; margin-top: 0px;

Products Name with link

91.8% Response Rate

Products Name with link

91.8% Response Rate

Products Name with link

91.8% Response Rate

FAQ

Q1. How long it will take to dry one batch?

A: It depends on the moisture cotent of drying material,size of material and drying degree. It depends on your real situation.

Q2. How about drying temperature?

A: Usually it is 40 ~ 150 °C, we can set this temperature according to your requirements.

Q3. How to package this big machine?

A: Packed in all fumigation plywood,Fixed in wooden at bottom and covered with plastic sheeting

width: 245px; height: 320px; margin-left: 0px; margin-top: 0px; width: 245px; height: 320px; margin-left: 0px; margin-top: 0px; width: 245px; height: 320px; margin-left: 0px; margin-top: 0px;How to Contact Us

Send your Inquiry Details in the Below, Click "Send " Now! Specific information and Accurate quotation are waiting for you.

Professional Industrial Vacuum Drying Oven is the use of rice flour, flour and other kinds of grain flour as raw materials to add some vitamins, trace elements and other high-nutrition ingredients mixed uniformly after extrusion curing and then for nutrition to strengthen the rice, after drying, shape, appearance taste edible method and natural The rice is consistent and supplements the lack of nutrients in natural rice. can also customize special rice with different functions according to different groups of people. Jinan Joysun Machinery Co., Ltd. has single screw rice extruder and twin screw extruder.
can be freely matched according to the requirements! Professional Industrial Vacuum Drying Oven technology is a breakthrough in the recycling of grain using the principle of extrusion. The most important feature of technology is the addition of various nutrients essential to the human body to food, producing a variety of health foods, curative foods and functional foods. The products are easy to eat and easy to use. Digestion and absorption, welcomed by consumers. Artificial rice alias nutrition rice, gold rice.
Jinan Joysun Machinery Co., Ltd. was established in 1993. It is located in Shandong Province with a registered capital of 2 million RMB and covers an area of 9,800 square meters. It is a professional food machinery manufacturing company integrating research and development, professional production, direct sales and after-sales services. We took the lead in awarding and passing the quality standards of commercial products in Shandong Province, and successfully passed ISO9001:2008 international quality management system certification, and exported to the European Union's CE safety certification, BV certification, third-party certification. Now we have successfully obtained the trademark.
