The best quality Circulation System drying oven machine for vegetable grain and fruit The best quality Circulation System drying oven machine for vegetable grain and fruit The best quality Circulation System drying oven machine for vegetable grain and fruit

The best quality Circulation System drying oven machine for vegetable grain and fruit

Product Description The best quality Circulation System drying oven machine for vegetable grain and fruit The best quality Circulation System drying oven machine...
  • INFO@LDFOODMACHINE.COM | Get Latest Price
  • Varied
  • Within 5 working days
  • paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
  • Contact with us
  • China
  • Snack Food Drying Oven
  • ISO
  • Snack Food Drying Oven

Product Description

Product Description

The best quality Circulation System drying oven machine for vegetable grain and fruit

width: 750px; height: 562.5px; margin-left: 0px; margin-top: 0px;

The best quality Circulation System drying oven machine for vegetable grain and fruit

Description :

The fruit and vegetable drying machine is mainly composed of drying chamber, material trays, ventilation system and temperature and moisture control system. It offers a flexible drying temperature, with a range of 50-90℃. Equipped with a moisture tester, user can know the moisture content via the display.

Equipment features :

1. The fuel can be used coal and electricity. According to the actual situation choose the best one.

2. The pre-set temperature range and enabling precise temperature-controlled drying.

3. There have standard box 20trays, 40trays, 60trays, 80trays,100trays,120trays four specifications, we can also customized.

4. The tray of drying system material are stainless steel and special plastic. The size of tray is 600X800X70mm, The size is uniform and have Strong interchangeability.

5. Low investment, safe and reliable operation, wide range of applications

6. Simple training can achieve more than one machine management operations, customers save human resources.

Specification Power supply Fan power (kW) Total power of Equipment (kW)
SJD-20 Electricity/Coal/wood 0.35 6
SJD-40 Electricity/Coal/wood 0.35 6
SJD-60 Electricity/Coal/wood 0.55 9
SJD-80 Coal/wood 0.75 3
SJD-100 Coal/wood 1.1 4.4
SJD-120 Coal/wood 2.2 8.8

Structure :

The thermostatic drying oven is mainly composed of drying chamber, combustor, electric heating tubes, ventilation system and control system.

1. Drying chamber

By utilizing stainless steel inside and coated steel plate outside, the drying chamber saves cost while ensures hygiene and corrosion resistance in the drying process.

2. Combustor

To cope with the smoke and fume produced during the process, the combustor is connected with a chimney, efficient and convenient.

3. Ventilation

When it comes to moisture control, the ventilation system plays an important role in balancing the moisture and air in the machine.

4. Control System

The control cabinet controls the electric heating tubes and fans. Additionally, it is installed with a temperature and moisture tester, which gives a convenient way to user for knowing the present condition.


Detailed Imageswidth: 426.667px; height: 320px; margin-left: -24px; margin-top: 0px; width: 426.667px; height: 320px; margin-left: -24px; margin-top: 0px; width: 426.667px; height: 320px; margin-left: -1px; margin-top: 0px; width: 426.667px; height: 320px; margin-left: -10px; margin-top: 0px; width: 701.333px; height: 526px; margin-left: -70px; margin-top: 0px; width: 244.656px; height: 326.208px; margin-left: 0px; margin-top: -37px; width: 244.656px; height: 326.208px; margin-left: 0px; margin-top: -12px; width: 244.656px; height: 326.208px; margin-left: 0px; margin-top: -9px;Other Productsmesh belt dryer width: 425.785px; height: 320px; margin-left: -14px; margin-top: 0px; width: 639.021px; height: 320px; margin-left: -41px; margin-top: 0px; width: 750px; height: 200.25px; margin-left: 0px; margin-top: 0px;Our Companywidth: 750px; height: 1222.63px; margin-left: 0px; margin-top: 0px;Our clientswidth: 426.667px; height: 320px; margin-left: -32px; margin-top: 0px; width: 426.667px; height: 320px; margin-left: -17px; margin-top: 0px; width: 371px; height: 494.667px; margin-left: 0px; margin-top: -116px; width: 427.807px; height: 320px; margin-left: -23px; margin-top: 0px;Packing & Deliverywidth: 750px; height: 1007.34px; margin-left: 0px; margin-top: 0px;Our Service

1. OEM Manufacturing welcome: Product, Package...
2. Sample order
3. We will reply you for your inquiry in 24 hours.
4. after sending, we will track the products for you once every two days, until you get the products. When you got the
goods, test them, and give me a feedback.If you have any questions about the problem, contact with us, we will offer
the solve way for you.

FAQwidth: 750px; height: 964px; margin-left: 0px; margin-top: 0px;

The best quality Circulation System drying oven machine for vegetable grain and fruit is suitable for foods such as casual products, soy products, meat, and aquatic products. is widely used in large, medium and small-sized fried food manufacturers, school canteens, and large-scale restaurants.
Jinan Joysun Machinery Co., Ltd. is a modern food machinery and equipment manufacturing enterprise integrating R&D, manufacturing, sales, and after-sales services.
The main production of food frying equipment, cleaning equipment, blanching cooking equipment, pasteurization line, drying machine, vacuum packaging machines and other food processing equipment.
The best quality Circulation System drying oven machine for vegetable grain and fruit is the essence of absorbing the same kind of equipment, retaining the advantages of large-scale equipment for enrichment, and referencing the user's feedback information throughout the country for design and development.
has the characteristics of low one-time investment, low energy consumption, multiple functions, small size, high profit, convenient use and maintenance. The full set of equipment consists of peeling, slicing (strips), fluttering, dehydration, oil-water mixed frying, degreasing, seasoning, packaging and auxiliary equipment.
