low temperature gas heating drying oven for dried fruit and melons low temperature gas heating drying oven for dried fruit and melons low temperature gas heating drying oven for dried fruit and melons

low temperature gas heating drying oven for dried fruit and melons

Gas heating drying oven Product Overview: CT-C series of hot air circulation oven with low noise with high temperature axial flow fan and automatic...
  • INFO@LDFOODMACHINE.COM | Get Latest Price
  • 2300*1200*2000mm
  • Within 5 working days
  • paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
  • Contact with us
  • China
  • Snack Food Drying Oven
  • ISO
  • Snack Food Drying Oven

Product Description

Gas heating drying oven

vertical-align: middle;

Product Overview:


CT-C series of hot air circulation oven with low noise with high temperature axial flow fan and automatic temperature control system, the circulatory system completely closed so that the thermal efficiency of oven traditional Drying-house from 3-7% to the current 35% to 45% The maximum thermal efficiency up to 50%. CT-C hot air circulation oven design success, and made China's hot air circulating oven at home and abroad to achieve the advanced level. China's saving a huge amount of energy, increase the economic efficiency of enterprises. 1990 issued by the State Administration of Traditional Chinese Medicine of the standards of conduct, unified model for RXH.

Principle:


Applicable to the pharmaceutical, chemical, food, agricultural and sideline products, aquatic products, light industry, Heavy industries, such as heating materials and products curing, drying dehydration. Raw materials such as medicine, health medicine, Chinese medicine Pieces, extract, powder, granules, granules, Shuiwan, bottles, paint dyes, dehydrated vegetables, melons and other fruits dry low temperature gas heating drying oven for dried fruit and melons, plastic resins, electrical components, such as Hongqi.

Description:


Heating steam heat, electricity, and far-infrared, gas, dual-use for users to choose
Temperature: 50-130 ℃ steam heating, the maximum 140 ℃
Electricity, far infrared temperature 50-300 ℃, supporting computer-controlled systems or control systems for users to choose
Common steam pressure 0.2-0.8 mpa (2-8kg/cm2)
Heating with electricity on a calculation of 15 kw, practical 5-8 kw / h
Special orders at the request
Non-standard price of oven -
℃ temperature greater than 140 or less than 60 ℃, it is necessary to specify when ordering
Our pre-baked cars, bake-size reunification, interchangeable
Bake-Size: 460 X640X45mm

Detailed picture

vertical-align: middle; vertical-align: middle;

Features:


Most of hot air circulating in the box, high thermal efficiency, energy conservation. Use mandatory ventilation role of the box with adjustable wind-board, uniform materials drying, heat can be steam, hot water, electricity, and far-infrared, and a wide choice. Complete machine noise, the running balance. Temperature-controlled, easy to install and maintain. Apply a wide range of different kinds of materials can be drying, drying equipment is common.

Technical parameters:

Model Drying amount each time(kg) Equipped power(kw) Consumption of steam(kg/h) Area of adiation(m²) Amount of air(m³/h) Temperature difference Amount of drying tray W*D*H(mm) Drying trolly
CT-C-0 60 0.45 10 10 3450 2 24 1480*1100*1750 1
CT-C-I 120 0.45 18 20 3450 2 48 2300*1200*2000 2
CT-C-II 240 0.9 36 40 6900 2 96 2300*2200*2000 4
CT-C-III 360 1.35 54 80 10350 2 144 2300*3200*2000 6
CT-C-IV 480 1.8 72 100 13800 2 192 4460*2200*2290 8

High effect and high temperature far infrared sterilization oven.

The power will be equipped in accordance with the requirements of temperature.

vertical-align: middle;

vertical-align: middle; vertical-align: middle;

Changzhou Haijiang Drying Equipment Co., Ltd. is a rise in the era of the sun industry pride, carrying the trend of the East China Sea, dazzling in the Yangtze River Delta by sea, Changzhou. since its inception in 2001,Relying on unique advantages of the region to bring the broad market, and more than 10 years of self-catching the continuous development of the company. haijiang has become key enterprises in China's dry industry trade.
Haijiang cover over 20,000 square meters ,have modern office plant more than 10,000 square meters, Haijiang is a professional manufacture of drying , granulation, pellting, coating, mixing, crushing, screening . Main products have 50 varieties and 600 models, with an annual output 1,000 sets, Haijiang is widely used in pharmaceutical, chemical, food, agricultural and sideline products processing, textiles, electronics, feed and other fields.

vertical-align: middle;

vertical-align: middle; vertical-align: middle; vertical-align: middle; vertical-align: middle;

low temperature gas heating drying oven for dried fruit and melons is suitable for foods such as casual products, soy products, meat, and aquatic products. is widely used in large, medium and small-sized fried food manufacturers, school canteens, and large-scale restaurants.
Jinan Joysun Machinery Co., Ltd. is a modern food machinery and equipment manufacturing enterprise integrating R&D, manufacturing, sales, and after-sales services.
The main production of food frying equipment, cleaning equipment, blanching cooking equipment, pasteurization line, drying machine, vacuum packaging machines and other food processing equipment.
low temperature gas heating drying oven for dried fruit and melons is the essence of absorbing the same kind of equipment, retaining the advantages of large-scale equipment for enrichment, and referencing the user's feedback information throughout the country for design and development.
has the characteristics of low one-time investment, low energy consumption, multiple functions, small size, high profit, convenient use and maintenance. The full set of equipment consists of peeling, slicing (strips), fluttering, dehydration, oil-water mixed frying, degreasing, seasoning, packaging and auxiliary equipment.
