Dried friut piece Drying Oven,CT-C/CT

Product Description Dried friut piece Drying Oven,CT-C/CT adopts noise elimination and thermal stable axial flow fan and automatic temperature control system. The entire...
  • INFO@LDFOODMACHINE.COM | Get Latest Price
  • Within 5 working days
  • paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
  • Contact with us
  • China
  • Snack Food Drying Oven
  • ISO9001:2008
  • Snack Food Drying Oven

Product Description

Product Description

Dried friut piece Drying Oven,CT-C/CT adopts noise elimination and thermal stable axial flow fan and automatic temperature control system. The entire circulation system is enclosed to make that the heat efficiency of the drying oven increases from 3~7% of the traditional drying oven to 35~45% of the present one. The highest heat efficiency can be up to 50%. The successful design of CT -C hot air circulation oven makes that the hot air circulation drying oven in our country reach the advanced level in the world. It saves energy and increases the economic benefit.

width: 750px; height: 555.75px; margin-left: 0px; margin-top: 0px;Main Features

1. The heat source can be steam, electricity, far infrared, or steam+electricity. Customer can select one of the heating ways in accordance with practical conditions;
2.The temperature of operation: 50 ~ 140 °C for steam, Maximum temperature will be 150 °C;
3.50 ~ 350 °C for electricity or far infrared;
4. There are automatic and computer control systems for customer selection;
5. The normal pressure of steam will be 0.02-0.8MPa (0.2-8kg/cm 2);
6. The equipped power of electric heater will be 15kw Calculated with Model I and the operational power to be used will be 5-8kw/hr;
7. for special requirement, please indicate it in order;
8. The price of non-standard oven shall be discussed additionally;
9. If the operation temperature is more than 140 °C or less than 60 °C, please indicate it in order;
10. The size of drying trolley and tray is standardized. They can be exchanged each other;
11 The size of drying tray: 460 ×640×45(mm).

Characteristics

Most hot air is circulated in the oven. The Heat efficiency is high and the energy is saved. By using the forced ventilation function, there are adjustable air distribution plates inside the oven. The materials can be dried uniformly. The heating source might be steam, hot water, electricity and far infrared. With a widely selection. The whole machine is low in the noise. The operation is in balance. The temperature is controlled automatically. The installation and maintenance are easy. The application is wide. The machine can be used for drying various materials and is general drying equipment.

Material to be dried

Dried friut piece Drying Oven,CT-C/CT is suitable for the material and product hot solidication and dry de-watering in the pharmaceutical, chemical, food, farming, side-product, aquatic product, light industries, heavy industries and others industries. Such as: raw material medicine, crude drug, prepared herbal medicine of Chinese traditional medicine, plaster , powder, particle, drinking agent, pill, packing bottle, pigment, dyestuff, de-watering vegetable, dried fruit piece, Dried friut piece Drying Oven,CT-C/CT, plastics, resin, electric component, baking varnish and etc.

Technical Parameterwidth: 750px; height: 383.312px; margin-left: 0px; margin-top: 0px;Company Picturewidth: 750px; height: 210.961px; margin-left: 0px; margin-top: 0px; width: 750px; height: 547.5px; margin-left: 0px; margin-top: 0px; width: 750px; height: 550.5px; margin-left: 0px; margin-top: 0px; width: 402.3px; height: 544.5px; margin-left: 0px; margin-top: -16px; width: 244.656px; height: 178.844px; margin-left: 0px; margin-top: 0px; width: 244.656px; height: 178.844px; margin-left: 0px; margin-top: 0px; width: 244.656px; height: 178.844px; margin-left: 0px; margin-top: 0px; width: 750px; height: 547.5px; margin-left: 0px; margin-top: 0px;

Dried friut piece Drying Oven,CT-C/CT is a food processing equipment developed, developed and produced on the basis of Jinan Joysun Machinery Co., Ltd. absorbing advanced foreign technologies. The technical performance and quality indicators of have reached the advanced level of similar international equipment. Dried friut piece Drying Oven,CT-C/CT From ingredients, extrusion, filling, forming, baking, spraying to finished products can be completed at one time, can produce all kinds of puffed foods, fragrant rice cakes, sandwich rolls (cakes) and crackers, cereal porridge, nutritional powder, etc. food. can produce all kinds of puffed foods, fragrant rice cakes and other sandwich rolls (cakes) and crisp biscuits, cereal porridge, nutritional powder and other foods. Using potato starch, corn starch, and flour as the main raw materials, the unique extrusion molding process is used to produce popular puffed foods with different shapes on the market. 222222 has a reasonable design, a high degree of automation, a clear control of extrusion parameters, the host is equipped with high and low pressure screws, increases the scope of use of raw materials, reduces costs, and improves product quality. The main products are spirals. Shells, round tubes, square tubes, circles, cartoon shapes, sports shapes, etc., produce products that are lifelike, crisp and crisp after being fried.
Jinan Joysun Machinery Co., Ltd. is a modern food machinery and equipment manufacturing enterprise integration R&D, manufacturing, sales, and after-sales services.
