Home >  Snack Food Drying Oven >  continuous drying oven
continuous drying oven continuous drying oven continuous drying oven

continuous drying oven

Product Description Main Properties: 1.Most of hot air is circled inside the oven. The heat efficiency is high and the energy source can be saving . 2.Using...
  • Snack Food Drying Oven
  • Snack Food Drying Oven
  • 2300X1200X2000 mm
  • Within 5 working days
  • paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
  • Contact with us
  • China
  • ISO 9001 and CE certificate

Product Description

Product Description

Main Properties:

1.Most of hot air is circled inside the oven. The heat efficiency is high and the energy source can be saving .

2.Using enhanced ventilation and adjustable air separating boards. It can make materials dried uniformly. The heat source can be steam, heat conductive oil, electricity or far infrared

3.The machine makes little noise and can be operated stably. The temperature can be controlled automatically and the installation and maintain are all very convenient

4With wide scope of application, it is suitable for drying varieties of materials, so it is a current type of drying equipment.


it is suitable for pharmaceutical industry. chemical industry, foodstuff industry.agricultural and sideline products. light industry. heavy industry and so on .

Technical Parameters:

Type Drying Capacity Powder Consumed Radiating Area Air capacity Top and Bottom Backing plate Overall Size(LXWΧH) Backing Cart
RXH-5-C 25 0.45 5 5 3400 0 16 1550X1000X2044 0
RXH-14-C 60 0.45 10 10 3400 ±2°c 24 1400X1200X2000 1
RXH-14-C 120 0.45 18 20 3450 ±2°c 48 2300X1200X2000 2
RXH-27-C 240 0.9 36 40 6900 ±2°c 96 2300X2200X2000 4
RXH-41-C 360 1.35 54 80 10350 ±2°c 144 2300X3200X2000 6
RXH-54-C 480 1.8 72 100 13800 ±2°c 192 4460X2200X2290 8


1: this oven is made up of stainless steel

2: this machine meeting iso 9001 and CE certificate

3; this machine can use the steam or electric, the consumer can select one, we also can made the oven can use the two soruce together

4: match the trays and trolleys, the trolley can movement , in and out

5: match the control panel, the temperature can adjust

6: the voltage: 220V or 380V or as consumer requirement

7: guarantee: 1 year

Packaging & Shipping

use the wood case as package, shipping : by sea, LCL, FCL

Our Services

the machine guarantee one year, technical service all life, 24 hotline service

Company Information

continuous drying oven is now a general-purpose model DL3000-100 single screw, is mainly used for the production of a variety of pasta, fried foods, rice noodles, pasta, pasta and other products, stable output, simple and convenient operation. 3000 is the length of the screw and 100 is the diameter of the screw.
continuous drying oven consists of feeding system, extrusion system, rotary cutting system, heating system, transmission system and control system. The use of advanced screw extrusion technology, the use of high temperature and high pressure material curing and expansion molding, one-time completion. The host adopts variable frequency speed regulation to ensure the stability of the production process. Product color, variety, appearance, natural and realistic, delicate texture, raw materials are widely used of .
Jinan Joysun Machinery Co., Ltd. is a high-tech enterprise integrating science, industry and trade. is dedicated to the development, development, production and sales of expanded snack food equipment, tissue protein equipment, pasta/pimento equipment, pet food equipment and experimental extruders.
Nowadays, Jinan Joysun Machinery Co., Ltd. have customers both in China and abroad.Foreign customers such as Russian,East Europe,Middle East,South America,North America,East Asia,Southeast Asia, Africa,etc.
