Product Description

baking varnish drying oven with hot air circulating system

1.Heat source can be steam,electricity,far infrared or steam +electricity.

2.Save plenty of energy cource and increase profit of enterprise.

3.Convenient of installation maintenace

Descriptions
CT-C hot air circulating oven is equipped with axial flow fan and automatic constant temperature control system. The computer control system is also available. The thermal efficiency of our hot air circulation tray dryer is up to 70%. The biggest characteristic of this drying equipment is that part of the hot air circulates inside the oven, and the whole circulating process is closed, thus enhancing heat transfer and energy saving.
Features of Hot Air Circulating Oven
1. This hot air circulation tray dryer has wide range of application, as general drying equipment can dry all kinds of materials.
2. Heat source can use steam, conduction oil, electricity, hot water and far infrared.
3. It has wide range of temperature adaptation, the normal temperature can be heated to 140ºC by steam and 350ºC by electric heating.
4. CT-C hot air circulation tray dryer has the advantages of small noise, stable movement, automatic temperature control, easy installation and maintenance.
5. The dimension of the standard drying tray is 460×640×45 mm.
6. Drying trolley can be manufactured with mobile type, easy to move out for cleaning and maintenance.


Application
CT-C hot air circulating oven is mainly used for heat curing, drying and dehydrating materials and products in food, pharmaceutical, chemical, feed, pesticide, light industry, heavy industry and other industries. Typical materials dried by our drying equipment are dehydrated vegetables, fruits, crude drugs, Chinese herbal pieces, powder, particles, dissolved medicines, pigments, baking varnish drying oven with hot air circulating system, plastic resin, electrical equipment and baking finish.
Technical Parameters of Hot Air Circulating Oven

Model CT-C-O CT-C-IA CT-C-I CT-C-II CT-C-IIA CT-C-III CT-C-IIIA CT-C-IV
Each Drying Amount (kg/lot) 30 60 120 240 240 360 360 480
Evaporation Area (m2) 4.7 7.1 14.1 28.3 28.3 42.4 42.4 56.5
Radiator Area (m2) 8 15 24 48 48 72 72 96
Steam Consumption (kg/h) 7 15 20 40 40 60 60 80
Electrical Heating Power (kw) 6-9 6-9 15 30 30 45 45 60
Fan Delivery (m2/h) 3450 3450 3450 6900 6900 10350 10350 13800
Fan Power (kw) 0.45 0.45 0.45 0.45 × 2 0.45 × 2 0.45 × 3 0.45 × 3 0.45 × 4
Temperature Difference (ºC) ± 1 ± 1 ± 2 ± 2 ± 2 ± 2 ± 2 ± 2
Outline Dimension (mm) (W × D × H) 1400 × 1200 × 2000 1400 × 1200 × 2000 2300 × 1200 × 2000 2300 × 2200 × 2000 4280 × 1200 × 2270 2260 × 3200 × 2000 3240 × 2200 × 2000 4280 × 2200 × 2270
Auxiliary Drying Cart (sets) 0 1 2 4 4 6 6 8
Auxiliary Drying Tray (pcs) 16 24 48 96 96 144 144 192
Total Weight (kg) 500 820 1580 1800 1880 2100 2210 2800

Company introcuction

margin: 0px; padding: 0px; border: 0px; font-style: inherit; font-weight: inherit; font-size: 0px; line-height: inherit; color: transparent; width: 644px; height: 484px; display: inline;

1.We use high-end imported brands of instruments and processing machines, to create superior quality machine for you ; yutong makes you feel free about the after-sales service.
2.We provide the spare parts with the cost of the spare parts themselves for life long time .

3.We can make the machine based on the customer requirements .

4.We have strong team ,and can help customer to design his process of the product .

5.Guarantee /warranty :1year. calculating from the day of successful installation and commissioning.

Factory inside

margin: 0px; padding: 0px; border: 0px; font-style: inherit; font-weight: inherit; font-size: 0px; line-height: inherit; color: transparent; width: 687px; height: 942px; display: inline;

margin: 0px; padding: 0px; border: 0px; font-style: inherit; font-weight: inherit; font-size: 0px; line-height: inherit; color: transparent; width: 686px; height: 940px; display: inline;

Processing&Our team

margin: 0px; padding: 0px; border: 0px; font-style: inherit; font-weight: inherit; font-size: 0px; line-height: inherit; color: transparent; width: 334px; height: 752px; display: inline; margin: 0px; padding: 0px; border: 0px; font-style: inherit; font-weight: inherit; font-size: 0px; line-height: inherit; color: transparent; width: 348px; height: 955px; display: inline;

Service

Pre-service

Introduce the product to the customer in detail,answer the question raised by customer carefully;

Sale service

1.Ensure product with high quality and pre-commissioning before delivery;

2.Delivery on time;

3.Provide full set of documents as customer’s requirements.

After-sale service

Provide considerate services to minimize clients’ worries.

1.Assist clients to prepare for the first construction scheme;

2.Install and debug the equipment;

3.Train the first-line operators;

4. Examine the equipment;5.Take initiative to eliminate the troubles rapidly;

6.Provide technical support;

7.Establish long-term and friendly relationship.

Service commitment

1. Provide clients one-year warranty to make sure the machine work well;

2.We always keep certain inventory level of spare parts, which means the replacements can be sent to you timely;

3.Send every client a preferential quotation.

Centrificate

margin: 0px; padding: 0px; border: 0px; font-style: inherit; font-weight: inherit; font-size: 0px; line-height: inherit; color: transparent; width: 627px; height: 627px; display: inline;

Exhibition

margin: 0px; padding: 0px; border: 0px; font-style: inherit; font-weight: inherit; font-size: 0px; line-height: inherit; color: transparent; width: 687px; height: 942px; display: inline;

margin: 0px; padding: 0px; border: 0px; font-style: inherit; font-weight: inherit; font-size: 0px; line-height: inherit; color: transparent; width: 687px; height: 942px; display: inline;

FAQ

1.Are you a manufacturer ,trading company or a third party

We are a manufacturer ,we set in 2000.

2.Where is your factory located

Our company is located in Changzhou city ,Jiansu province,China .it is In the middle of Shanghai and nanjing

baking varnish drying oven with hot air circulating system is now a general-purpose model DL3000-100 single screw, is mainly used for the production of a variety of pasta, fried foods, rice noodles, pasta, pasta and other products, stable output, simple and convenient operation. 3000 is the length of the screw and 100 is the diameter of the screw.
baking varnish drying oven with hot air circulating system consists of feeding system, extrusion system, rotary cutting system, heating system, transmission system and control system. The use of advanced screw extrusion technology, the use of high temperature and high pressure material curing and expansion molding, one-time completion. The host adopts variable frequency speed regulation to ensure the stability of the production process. Product color, variety, appearance, natural and realistic, delicate texture, raw materials are widely used of .
Jinan Joysun Machinery Co., Ltd. is a high-tech enterprise integrating science, industry and trade. is dedicated to the development, development, production and sales of expanded snack food equipment, tissue protein equipment, pasta/pimento equipment, pet food equipment and experimental extruders.
Nowadays, Jinan Joysun Machinery Co., Ltd. have customers both in China and abroad.Foreign customers such as Russian,East Europe,Middle East,South America,North America,East Asia,Southeast Asia, Africa,etc.
